FOR-A FA-9500 - 20-3. AFD Supported Video Formats

249
Object group
Menu name in
FA-9500
Item name in
FA-9500
Description Object name in MIB file OID Type Write Read Trap
Trap
event
(value)
OID: 1.3.6.1.4.1.20175.1.301.5.2.(Input/Output Video format)
VIDEO IN
VIDEO OUT
STATUS
SDI OUT /2
00: Loss
01: 525/60i
02: 625/50i
03: 1080/60i
04: 1080/59i
05: 1080/50i
06: 1080/30PsF
07: 1080/29.97PsF
08: 1080/25PsF
09: 1080/24PsF
10: 1080/23.98PsF
11: 1080/60p
12: 1080/59p
13: 1080/50p
14: 1080/30p
15: 1080/29.97p
16: 1080/25p
17: 1080/24p
18: 1080/23.98p
19: 720/60p
20: 720/59p
21: 720/50p
22: 720/30p
23: 720/29.97p
24: 720/25p
25: 720/24p
26: 720/23.98p
27: 1035/60i
28: 1035/59i
29: Unknown
30: BY-PASS
31: Disable
32: none
fa95OutSDI1-2 21 INTEGER - ○ ○ Change
SDI OUT 3/4
Same as above
fa95OutSDI3-4 22 INTEGE
R
- ○ ○ Change
Composite OUT
0: Loss
1: 525/60
2: 625/50
30: BY-PASS
31:Disable
fa95OutComposite 23 INTEGER - ○ ○ Change
COMPONENT
STATUS
VIDEO IN
STATUS
COMPONENT IN
00: Loss
01: 525/60i
02: 625/50i
03: 1080/60i
04: 1080/59i
05: 1080/50i
06: 1080/30PsF
07: 1080/29.97PsF
08: 1080/25PsF
09: 1080/24PsF
10: 1080/23.98PsF
11: 1080/60p
12: 1080/59p
13: 1080/50p
14: 1080/30p
15: 1080/29.97p
16: 1080/25p
17: 1080/24p
18: 1080/23.98p
19: 720/60p
20: 720/59p
21: 720/50p
22: 720/30p
23: 720/29.97p
24: 720/25p
25: 720/24p
26: 720/23.98p
27: 1035/60i
28: 1035/59i
29: Unknown
30: BY-PASS
31: DISABLE
32: none
fa95InComponent 101 INTEGER - ○ ○ -
VIDEO OUT
STATUS
COMPONENT OUT
Same as above
fa95OutComponent 102 INTEGER - ○ ○ -
OID: 1.3.6.1.4.1.20175.1.301.5.1.(Unit alarm)
UNIT
UNIT
ALARM
FAN1
0: Normal
1: Stopped
fa95Fan1Status 1 INTEGER - ○ ○ Change
FAN2
0: Normal
1: Stopped
fa95Fan2Status 2 INTEGER - ○ ○ Change
Power1
-1: Not Install
0: Normal
1: Ab normal
fa95Power1Status 11 INTEGER - ○ ○ Change
Power2
-1: Not Install
0: Normal
1: Ab normal
fa95Power2Status 12 INTEGER - ○ ○ Change
