FOR-A FA-9500 - 20-4. AFD Based Auto Aspect Conversion Settings

250
Object group
Menu name in
FA-9500
Item name in
FA-9500
Description Object name in MIB file OID Type Write Read Trap
Trap
event
(value)
OID: 1.3.6.1.4.1.20175.1.301.5.3.11.(Audio source status)
SOURCE
AUDIO
SOURCE
AUDIO
CH1
0: Loss
1: PCM
2: PCM 48kHz
3: PCM 44.1kHz
4: PCM 32kHz
5: PCM Other
6: Silence
7: Silence 48kHz
8: Silence 44.1kHz
9: Silence 32kHz
10: Silence Other
11: NON-PCM
12: PCM(Async)
13: Silence(Async)
14: NON-PCM(Async)
15: IN（Analog）
16: Unknown
fa95StatusAudioSourceCh1 1 INTEGER - ○ ○ Change
CH2 同上 fa95StatusAudioSourceCh2 2 INTEGE
R
- ○ ○ Change
CH3 同上 fa95StatusAudioSourceCh3 3 INTEGE
R
- ○ ○ Change
CH4 同上 fa95StatusAudioSourceCh4 4 INTEGE
R
- ○ ○ Change
CH5 同上 fa95StatusAudioSourceCh5 5 INTEGE
R
- ○ ○ Change
CH6 同上 fa95StatusAudioSourceCh6 6 INTEGE
R
- ○ ○ Change
CH7 同上 fa95StatusAudioSourceCh7 7 INTEGE
R
- ○ ○ Change
CH8 同上 fa95StatusAudioSourceCh8 8 INTEGE
R
- ○ ○ Change
CH9 同上 fa95StatusAudioSourceCh9 9 INTEGE
R
- ○ ○ Change
CH10 同上 fa95StatusAudioSourceCh10 10 INTEGE
R
- ○ ○ Change
CH11 同上 fa95StatusAudioSourceCh11 11 INTEGE
R
- ○ ○ Change
CH12 同上 fa95StatusAudioSourceCh12 12 INTEGE
R
- ○ ○ Change
CH13 同上 fa95StatusAudioSourceCh13 13 INTEGE
R
- ○ ○ Change
CH14 同上 fa95StatusAudioSourceCh14 14 INTEGE
R
- ○ ○ Change
CH15 同上 fa95StatusAudioSourceCh15 15 INTEGE
R
- ○ ○ Change
CH16 同上 fa95StatusAudioSourceCh16 16 INTEGE
R
- ○ ○ Change
OID: 1.3.6.1.4.1.20175.1.301.5.3.1.(SDI1 input audio status)
AUDIO IN
SDI 1 IN
AUDIO
CH1
0: Loss
1: PCM
2: Silence
3: NON-PCM
4: PCM(Async)
5: Silence(Async)
6: NON-PCM(Async)
7: Unknown
8: Bypass
9: Blank
10:Disable
fa95StatusSdiEmbIn1Ch1 1 INTEGER - ○ - -
CH2
Same as above
fa95StatusSdiEmbIn1Ch2 2 INTEGE
R
- ○ - -
CH3
Same as above
fa95StatusSdiEmbIn1Ch3 3 INTEGE
R
- ○ - -
CH4
Same as above
fa95StatusSdiEmbIn1Ch4 4 INTEGE
R
- ○ - -
CH5
Same as above
fa95StatusSdiEmbIn1Ch5 5 INTEGE
R
- ○ - -
CH6
Same as above
fa95StatusSdiEmbIn1Ch6 6 INTEGE
R
- ○ - -
CH7
Same as above
fa95StatusSdiEmbIn1Ch7 7 INTEGE
R
- ○ - -
CH8
Same as above
fa95StatusSdiEmbIn1Ch8 8 INTEGE
R
- ○ - -
CH9
Same as above
fa95StatusSdiEmbIn1Ch9 9 INTEGE
R
- ○ - -
CH10
Same as above
fa95StatusSdiEmbIn1Ch10 10 INTEGE
R
- ○ - -
CH11
Same as above
fa95StatusSdiEmbIn1Ch11 11 INTEGE
R
- ○ - -
CH12
Same as above
fa95StatusSdiEmbIn1Ch12 12 INTEGE
R
- ○ - -
CH13
Same as above
fa95StatusSdiEmbIn1Ch13 13 INTEGE
R
- ○ - -
CH14
Same as above
fa95StatusSdiEmbIn1Ch14 14 INTEGE
R
- ○ - -
CH15
Same as above
fa95StatusSdiEmbIn1Ch15 15 INTEGE
R
- ○ - -
CH16
Same as above
fa95StatusSdiEmbIn1Ch16 16 INTEGE
R
- ○ - -
OID: 1.3.6.1.4.1.20175.1.301.5.3.2.
(
SDI2 input audio status
)
AUDIO IN
SDI 2 IN
AUDIO
CH1
0: Loss
1: PCM
2: Silence
3: NON-PCM
4: PCM(Async)
5: Silence(Async)
6: NON-PCM(Async)
7: Unknown
8: Bypass
9: Blank
10:Disable
fa95StatusSdiEmbIn2Ch1 1 INTEGER - ○ - -
CH2
Same as above
fa95StatusSdiEmbIn2Ch2 2 INTEGE
R
- ○ - -
CH3
Same as above
fa95StatusSdiEmbIn2Ch3 3 INTEGE
R
- ○ - -
CH4
Same as above
fa95StatusSdiEmbIn2Ch4 4 INTEGE
R
- ○ - -
CH5
Same as above
fa95StatusSdiEmbIn2Ch5 5 INTEGE
R
- ○ - -
CH6
Same as above
fa95StatusSdiEmbIn2Ch6 6 INTEGE
R
- ○ - -
CH7
Same as above
fa95StatusSdiEmbIn2Ch7 7 INTEGE
R
- ○ - -
CH8
Same as above
fa95StatusSdiEmbIn2Ch8 8 INTEGE
R
- ○ - -
CH9
Same as above
fa95StatusSdiEmbIn2Ch9 9 INTEGE
R
- ○ - -
CH10
Same as above
f
a95StatusSdiEmbIn2Ch10 10 INTEGE
R
- ○ - -
CH11
Same as above
fa95StatusSdiEmbIn2Ch11 11 INTEGE
R
- ○ - -
CH12
Same as above
fa95StatusSdiEmbIn2Ch12 12 INTEGE
R
- ○ - -
CH13
Same as above
fa95StatusSdiEmbIn2Ch13 13 INTEGE
R
- ○ - -
CH14
Same as above
fa95StatusSdiEmbIn2Ch14 14 INTEGE
R
- ○ - -
CH15
Same as above
fa95StatusSdiEmbIn2Ch15 15 INTEGE
R
- ○ - -
CH16
Same as above
fa95StatusSdiEmbIn2Ch16 16 INTEGE
R
- ○ - -
