FOR-A FA-9500 - Page 267

251
Object group
Menu name in
FA-9500
Item name in
FA-9500
Description Object name in MIB file OID Type Write Read Trap
Trap
event
(value)
OID: 1.3.6.1.4.1.20175.1.301.5.3.3.(AES input audio status)
AUDIO IN AES IN AUDIO
CH1
0: Loss
1: PCM 48kHz
2: PCM 44.1kHz
3: PCM 32kHz
4: PCM Other
5: Silence 48kHz
6: Silence 44.1kHz
7: Silence 32kHz
8: Silence Other
9: NON-PCM
10: Unknown
11: Output Setting
fa95StatusAesInCh1(1) 1 INTEGER - ○ - -
CH2
Same as above
fa95StatusAesInCh2(2) 2 INTEGE
R
- ○ - -
CH3
Same as above
fa95StatusAesInCh3(3) 3 INTEGE
R
- ○ - -
CH4
Same as above
fa95StatusAesInCh4(4) 4 INTEGE
R
- ○ - -
CH5
Same as above
fa95StatusAesInCh5(5) 5 INTEGE
R
- ○ - -
CH6
Same as above
fa95StatusAesInCh6(6) 6 INTEGE
R
- ○ - -
CH7
Same as above
fa95StatusAesInCh7(7) 7 INTEGE
R
- ○ - -
CH8
Same as above
fa95StatusAesInCh8(8) 8 INTEGE
R
- ○ - -
OID: 1.3.6.1.4.1.20175.1.301.5.3.4.
(
A
NALOG Input Audio Status
)
AUDIO IN
ANALOG IN
AUDIO
CH1
0: Loss
1: IN
fa95StatusAnalogInCh1 1 INTEGER - ○ - -
CH2
Same as above
fa95StatusAnalogInCh2 2 INTEGE
R
- ○ - -
CH3
Same as above
fa95StatusAnalogInCh3 3 INTEGE
R
- ○ - -
CH4
Same as above
fa95StatusAnalogInCh4 4 INTEGE
R
- ○ - -
OID: 1.3.6.1.4.1.20175.1.301.5.3.21.(SDI1/2 output audio status)
AUDIO OUT
SDI1/2 OUT
AUDIO
CH1
0: Loss
1: PCM
2: Silence
3: NON-PCM
4: PCM(Async)
5: Silence(Async)
6: NON-PCM(Async)
7: Unknown
8:BY-PASS
9:Blank
fa95StatusSdiEmbOut1-2Ch1(1) 1 INTEGER - ○ - -
CH2
Same as above
fa95StatusSdiEmbOut1-2Ch2(2) 2 INTEGE
R
- ○ - -
CH3
Same as above
fa95StatusSdiEmbOut1-2Ch3(3) 3 INTEGE
R
- ○ - -
CH4
Same as above
fa95StatusSdiEmbOut1-2Ch4(4) 4 INTEGE
R
- ○ - -
CH5
Same as above
fa95StatusSdiEmbOut1-2Ch5(5) 5 INTEGE
R
- ○ - -
CH6
Same as above
fa95StatusSdiEmbOut1-2Ch6(6) 6 INTEGE
R
- ○ - -
CH7
Same as above
fa95StatusSdiEmbOut1-2Ch7(7) 7 INTEGE
R
- ○ - -
CH8
Same as above
fa95StatusSdiEmbOut1-2Ch8(8) 8 INTEGE
R
- ○ - -
CH9
Same as above
fa95StatusSdiEmbOut1-2Ch9(9) 9 INTEGE
R
- ○ - -
CH10
Same as above
fa95StatusSdiEmbOut1-2Ch10(10) 10 INTEGE
R
- ○ - -
CH11
Same as above
fa95StatusSdiEmbOut1-2Ch11(11) 11 INTEGE
R
- ○ - -
CH12
Same as above
fa95StatusSdiEmbOut1-2Ch12(12) 12 INTEGE
R
- ○ - -
CH13
Same as above
fa95StatusSdiEmbOut1-2Ch13(13) 13 INTEGE
R
- ○ - -
CH14
Same as above
fa95StatusSdiEmbOut1-2Ch14(14) 14 INTEGE
R
- ○ - -
CH15
Same as above
fa95StatusSdiEmbOut1-2Ch15(15) 15 INTEGE
R
- ○ - -
CH16
Same as above
fa95StatusSdiEmbOut1-2Ch16(16) 16 INTEGE
R
- ○ - -
OID: 1.3.6.1.4.1.20175.1.301.5.3.22.(SDI3/4 output audio status)
AUDIO OUT
SDI3/4 OUT
AUDIO
CH1
0: Loss
1: PCM
2: Silence
3: NON-PCM
4: PCM(Async)
5: Silence(Async)
6: NON-PCM(Async)
7: Unknown
8:BY-PASS
9:Blank
fa95StatusSdiEmbOut3-4Ch1 1 INTEGER - ○ - -
CH2 Same as above fa95StatusSdiEmbOut3-4Ch2 2 INTEGE
R
- ○ - -
CH3 Same as above fa95StatusSdiEmbOut3-4Ch3 3 INTEGE
R
- ○ - -
CH4 Same as above fa95StatusSdiEmbOut3-4Ch4 4 INTEGE
R
- ○ - -
CH5 Same as above fa95StatusSdiEmbOut3-4Ch5 5 INTEGE
R
- ○ - -
CH6 Same as above fa95StatusSdiEmbOut3-4Ch6 6 INTEGE
R
- ○ - -
CH7 Same as above fa95StatusSdiEmbOut3-4Ch7 7 INTEGE
R
- ○ - -
CH8 Same as above fa95StatusSdiEmbOut3-4Ch8 8 INTEGE
R
- ○ - -
CH9 Same as above fa95StatusSdiEmbOut3-4Ch9 9 INTEGE
R
- ○ - -
CH10 Same as above fa95StatusSdiEmbOut3-4Ch10 10 INTEGE
R
- ○ - -
CH11 Same as above fa95StatusSdiEmbOut3-4Ch11 11 INTEGE
R
- ○ - -
CH12 Same as above fa95StatusSdiEmbOut3-4Ch12 12 INTEGE
R
- ○ - -
CH13 Same as above fa95StatusSdiEmbOut3-4Ch13 13 INTEGE
R
- ○ - -
CH14 Same as above fa95StatusSdiEmbOut3-4Ch14 14 INTEGE
R
- ○ - -
CH15 Same as above fa95StatusSdiEmbOut3-4Ch15 15 INTEGE
R
- ○ - -
CH16 Same as above fa95StatusSdiEmbOut3-4Ch16 16 INTEGE
R
- ○ - -
OID: 1.3.6.1.4.1.20175.1.301.5.3.23.(AES output audio status)
AUDIO OUT
AES OUT
AUDIO
CH1
0: Loss
1: PCM
2: silence
3: NON-PCM
4: PCM(Async)
5: Silence(Async)
6: NON-PCM(Async)
7: Unknown
8: Input Setting
fa95StatusAesOutCh1 1 INTEGER - ○ - -
CH2 Same as above fa95StatusAesOutCh2 2 INTEGE
R
- ○ - -
CH3 Same as above fa95StatusAesOutCh3 3 INTEGE
R
- ○ - -
CH4 Same as above fa95StatusAesOutCh4 4 INTEGE
R
- ○ - -
CH5 Same as above fa95StatusAesOutCh5 5 INTEGE
R
- ○ - -
CH6 Same as above fa95StatusAesOutCh6 6 INTEGE
R
- ○ - -
CH7 Same as above fa95StatusAesOutCh7 7 INTEGE
R
- ○ - -
CH8 Same as above fa95StatusAesOutCh8 8 INTEGE
R
- ○ - -
