FOR-A FA-9500 - Page 268

252
Object group
Menu name in
FA-9500
Item name in
FA-9500
Description Object name in MIB file OID Type Write Read Trap
Trap
event
(value)
OID: 1.3.6.1.4.1.20175.1.301.5.3.24.(
A
nalog Output Audio Status)
AUDIO OUT
ANALOG Out
AUDIO
CH1
0: Silence
1: Out
fa95StatusAnalogOutCh1 1 INTEGER - ○ - -
CH2 Same as above fa95StatusAnalogOutCh2 2 INTEGE
R
- ○ - -
CH3 Same as above fa95StatusAnalogOutCh3 3 INTEGE
R
- ○ - -
CH4 Same as above fa95StatusAnalogOutCh4 4 INTEGE
R
- ○ - -
OID: 1.3.6.1.4.1.20175.1.301.5.3.100.(Dolby AUX Connector Status)
AUDIO
Option
Dolby AUX
STATUS
AUX Input
0: Loss
1: PCM
2: NON-PCM
3: Unknown
fa95StatusDolbyAuxIn 1 INTEGER - ○ ○ Change
AUX Output
0: PCM
1: NON-PCM
2: None
fa95StatusDolbyAuxOut 2 INTEGER - ○ - -
Reference Input
00: Loss
01: 525/60i
02: 625/50i
03: 1080/60i
04: 1080/59i
05: 1080/50i
06: 1080/30PsF
07: 1080/29.97PsF
08: 1080/25PsF
09: 1080/24PsF
10: 1080/23.98PsF
11: 1080/60p
12: 1080/59p
13: 1080/50p
14: 1080/30p
15: 1080/29.97p
16: 1080/25p
17: 1080/24p
18: 1080/23.98p
19: 720/60p
20: 720/59p
21: 720/50p
22: 720/30p
23: 720/29.97p
24: 720/25p
25: 720/24p
26: 720/23.98p
27: 1035/60i
28: 1035/59i
29: Unknown
30: BY-PASS
31: Disable
32: none
fa95StatusDolbyRefIn 3 INTEGER - ○ ○ Change
