FOR-A HVS-XT100 User Manual

132
When STILL is selected for TYPE:
Setting
Function
Button Indication
STILL1-2 STORE
Performs still captures.
Always lit orange
INPUT1-8 STILL STORE
Captures and saves or clears a still image for
INPUT STILL 1 to 8.
Image stored: Lit orange,
Image not stored: Lit white
INPUT STILL STORE
Captures and saves or clears a still image for
INPUT STILLs using KEY/AUX bus
 See section 5-4. "INPUT STILL."
Lit orange when pressed
CLIP 1-2 PLAY/PAUSE
Begins to play the recorded clip or pauses the
playback/recording.
During play: Lit green
Other cases : Lit white
CLIP 1-2 STOP
Stops clip playback and cues to IN point.
During stop: Lit orange
Other cases : Lit white
CLIP 1-2 REC
Begins to record video
During recording: Lit red
Other cases : Lit white
When AUX is selected for TYPE:
Setting
Function
Button Indication
AUX5-8 XPT SELECT
Allows the AUX output signal to be selected
using the KEY/AUX bus buttons.
ON: Lit orange
OFF: Lit white
AUX1-8 TRANS ENABLE
Sets AUX crossfade transition On/Off.
AUX LINK ENABLE
Enables all AUX links.
When OTHER is selected for TYPE:
Setting
Function
Button Indication
EDITOR ENABLE
Sets editor control On/Off.
ON: Lit orange
OFF: Lit white
WIPE MOD RESET
Resets the [WIPE] menu.
Always lit white
CG WIPE ENABLE
Enables CG WIPE.
ON: Lit orange
OFF: Lit white
ROUTER ENABLE
Enables router control.
ON: Lit orange
OFF: Lit white
SUBEFF1-2 FLD FREEZE
Enables FIELD FREEZE in a Sub Effect
channel.
ON: Lit orange
OFF: Lit white
SUBEFF1-2 FRM FREEZE
Enables FRAME FREEZE in a Sub Effect
channel.
ON: Lit orange
OFF: Lit white
ASSIGN INHI ENABLE
Enables the bus button inhibit function.
ON: Lit orange
OFF: Lit white
FS ENABLE
Enables frame synchronization for each input
using the KEY/AUX bus.
 See section 5-7."Frame Synchronizer."
ON: Lit orange
OFF: Lit white
JOY-STICK FINE
Enables fine control of the joystick.
ON: Lit orange
OFF: Lit white
EVENT NO.00-09 RECALL
Loads an event.
Event stored: Lit orange
Event not stored: Lit white
MACRO BUS SELECT
Sets the KEY/AUX bus to Macro mode.
To exit the Macro mode, press a bus selection
button (KEY1-2, DSK1-2 or AUX1-4).
 See section 16-4-1. "Changing KEY/AUX
Bus Buttons to Macro EXE Buttons."
ON: Lit orange
OFF: Lit white
