Frontier LP7700 - Compatibility of PCBs and electrical parts

Compatibility of PCBs and electrical parts
1/2
6. Electrical parts
60100
60100
Compatibility of PCBs and electrical parts
Compatibility of PCBs and electrical parts
!
!!
! Explanation
• The PCB and the parts No. used in the PCB installed on the system varies depending on the machine type.
• The corrective actions after replacing the PCBs may differ depending on system model though the parts No. of PCB is the same in
the list. Be sure to confirm the explanation of each PCB when replacing the parts.
!
!!
! Control PCB
*1. No longer available
!
!!
! PCB (other parts)
Reference
☞Control PCB ☞PCB (other parts) ☞Power supply PCB ☞Exposure engine
Name Part No. Manual No. Remarks
Printer control PCB J391423
☞66000
Laser control PCB J391465 ☞ 66010
Processor control PCB J391467
☞66200
Printer I/F main PCB J391489
J391391
*1
☞66005
Capacity booster PCB F J391452
☞66008
Capacity booster PCB G J391453
Capacity booster PCB H J391454
Capacity booster PCB I J391455
Name Part No. Manual No. Remarks
G-AOM driver Z025645 ☞66080
G laser driver J391231 ☞ 66070
J391160
Operation key PCB J391400
☞66095
Printer I/O PCB 1 J391483
☞66020
Printer I/O PCB 2 J391256
☞66030
Printer I/O PCB 3 J391253 ☞66040
Processor I/O PCB 1 J391468
☞66210
Processor I/O PCB 2 J391490
☞66211
CVP PCB J391258 ☞66090
Triple magazine PCB J391257 ☞66050
Quad magazine PCB J391177 ☞66055
Processor relay PCB J391466
☞66220
SM I/O PCB J391378 ☞66600 Only for [SM]
Tablet replenishment driver PCB J391351 ☞66500 Only for [J]
F replenishment I/O PCB J391322
☞66800 Only for [F]
Temperature and humidity sensor I096003
☞63280
Control strip driver PCB J391422
☞66810 Option
Control strip communication PCB J391404
☞66820
Infrared communication unit W413078
W413080
☞66830
Order specifying LED PCB 1 J490423
☞66840
Order specifying LED PCB 2 J391425 ☞66850
Order specifying LED PCB 3 J391426 ☞66860
Drive motor driver PCB I123279
☞66870
