Chapter 2 - Discovery LS System Safety Information Page 69
Example:
CAUTION
TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVERS.
REFER SERVICING TO
QUALIFIED PERSONNEL
Location:
Gantry, electronics cabinet, and DRAGON near
rating label or operating point.
Instructions:
This is a user label. A reasonable level of training
and technical expertise are expected before
access to these areas is allowed.
Yellow
CAUTION - 120V
LOCK-OUT AND TAG-OUT
TABLE/GANTRY POWER AT THE
PDU BEFORE ANY SERVICE IS
PERFORMED IN THIS AREA
Location:
PDU cover or vicinity of pcu cover.
Instructions:
Hazardous electrical conditions are expected in
the PCU. It is advised to follow the label
instructions before removing the PCU covers.
Yellow
CAUTION
HIGH CURRENT
LOCK-OUT AND TAG-OUT
REDDOG/HV AT THE
PDU BEFORE ANY
SERVICE IN THIS AREA
Location:
On each REDDOG chassis at the 5 volt high
current circuit, from the power supply to the VME
backplane.
Instructions:
A high current hazard is present at the backplane
of the REDDOG and its power supply. Follow the
label instructions or severe burns may be caused
by accidental short circuits.
Yellow
