Table 66: MX SCBE LEDs
DescriptionStateColorLabel
Fabric is in active mode.On steadilyGreenFABRIC
ACTIVE
MX SCBE operates in fabric-only mode.On steadilyGreenFABRIC
ONLY
MX SCBE operates in fabric/control board mode.Off–
MX SCBE is online.On steadilyGreenOK/FAIL
MX SCBE has failed.On steadilyRed
MX SCBE is offline.Off–
GPS clocking interface has failed.On steadilyRed
GPS clocking interface is offline.Off–
NOTE: The LEDs BITS, GPS, and UTI are not currently supported.
Building-integrated timing supply (BITS) clocking
interface is active.
On steadilyGreenBITS
BITS clocking interface has failed.On steadilyRed
BITS clocking interface is offline.Off–
Global positioning system (GPS) clocking interface
is active.
On steadilyGreenGPS
GPS clocking interface has failed.On steadilyRed
GPS clocking interface is offline.Off–
Universal Timing Interface (UTI) clocking interface
is active.
On steadilyGreenUTI
UTI clocking interface has failed.On steadilyRed
UTI clocking interface is offline.Off–
Related
Documentation
MX480 SCBE Description on page 110•
• MX480 Host Subsystem Description on page 25
• Upgrading an MX480 SCB on page 385
