See Also Preventing Electrostatic Discharge Damage to an MX480 Router on page 484•
• Installing an SFP or XFP Transceiver into an MX480 DPC, MPC, MIC, or PIC on page 285
• Replacing a Cable on an MX480 DPC, MPC, MIC, or PIC on page 328
Installing an SFP or XFP Transceiver into an MX480 DPC, MPC, MIC, or PIC
To install an SFP or XFP:
1. Attach an ESD grounding strap to your bare wrist and connect the strap to one of the
ESD points on the chassis.
2. Take each transceiver to be installed out of its electrostatic bag, and identify the slot
on the component where it will be installed.
3. Verify that each transceiver is covered by a rubber safety cap. If it is not, cover the
transceiver with a safety cap.
4. Carefully align the transceiver with the slots in the component. The connectors should
face the component.
5. Slide the transceiver until the connector is seated in the component slot. If you are
unable to fully insert the transceiver, make sure the connector is facing the right way.
6. Close the ejector handle of the transceiver.
7. Remove the rubber safety cap from the transceiver and the end of the cable. Insert
the cable into the transceiver.
WARNING: Do not look directly into a fiber-optic transceiver or into the
ends of fiber-optic cables. Fiber-optic transceivers and fiber-optic cable
connected to a transceiver emit laser light that can damage your eyes.
8. Verify that the status LEDs on the component faceplate indicate that the SFP or XFP
is functioning correctly. For more information about the component LEDs, see the MX
Series Interface Module Reference.
See Also Preventing Electrostatic Discharge Damage to an MX480 Router on page 484•
• Removingan SFP or XFP Transceiver from an MX480 DPC, MPC, MIC, or PIC on page399
• Replacing a Cable on an MX480 DPC, MPC, MIC, or PIC on page 328
401Copyright © 2017, Juniper Networks, Inc.
Chapter 27: Replacing Switch Fabric Components
