CAUTION: Do not leave a fiber-optic transceiver uncovered except when
you are inserting or removing cable. The safety cap keeps the port clean
and prevents accidental exposure to laser light.
4. Remove the cable from the cable management brackets.
5. Disconnect the cable from the destination port.
See Also Preventing Electrostatic Discharge Damage to an MX480 Router on page 484•
• Installing a Cable on an MX480 DPC, MPC, MIC, or PIC on page 259
• Maintaining Cables That Connect to MX480 DPCs, MPCs, MICs, or PICs on page 434
Installing a Cable on an MX480 DPC, MPC, MIC, or PIC
To install a cable:
1. Have ready a length of the type of cable used by the DPC, MPC, MIC, or PIC. For cable
specifications, see the MX Series Interface Module Reference.
2. If the cable connector port is covered by a rubber safety plug, remove the plug.
WARNING: Do not look directly into a fiber-optic transceiver or into the
ends of fiber-optic cables. Fiber-optic transceivers and fiber-optic cable
connected to a transceiver emit laser light that can damage your eyes.
CAUTION: Do not leave a fiber-optic transceiver uncovered except when
you are inserting or removing cable. The safety cap keeps the port clean
and prevents accidental exposure to laser light.
3. Insert the cable connector into the cable connector port on the component faceplate.
4. Arrange the cable in the cable management brackets to prevent it from dislodging or
developing stress points. Secure the cable so that it is not supporting its own weight
as it hangs to the floor. Place excess cable out of the way in a neatly coiled loop.
Placing fasteners on the loop helps to maintain its shape.
CAUTION: Do not let fiber-optic cable hang free from the connector. Do
not allow fastened loops of cable to dangle, which stresses the cable at
the fastening point.
Copyright © 2017, Juniper Networks, Inc.330
MX480 3D Universal Edge Router Hardware Guide
