Holding an MX480 FPC
CAUTION: Many components on the FPC are fragile. Failure to handle FPCs
as specified in this document can cause irreparable damage.
NOTE: An FPC configured with PICs installed can weigh as much as
18 lb (8.2 kg). Be prepared to accept the full weight of the FPC as you lift it.
CAUTION: To prevent damage when handling or carrying FPCs:
•
As you carry the FPC, do not bump it against anything. FPC components
are fragile.
•
Do not graspthe FPC anywhere exceptplaces that this document indicates.
In particular, never grasp the connector edge, especially at the power
connector in the corner where the connector and bottom edges meet (see
Figure 170 on page 427).
Figure 170: Do Not Grasp the Connector Edge
•
Do not carry the FPC by the faceplate with only one hand (see
Figure 171 on page 428).
