Bus Revision 42
FPGA Revision 1
To check the status of a specific SCB, issue the show chassis environment cb command
and include the slot number of the SCB. The output is similar to the following:
user@host> show chassis environment cb 0
CB 0 status:
State Online
Temperature Intake 66 degrees C / 150 degrees F
Temperature Exhaust A 67 degrees C / 152 degrees F
Temperature Exhaust B 73 degrees C / 163 degrees F
Power
1.2 V 1153 mV
1.5 V 1417 mV
1.8 V 1704 mV
2.5 V 2375 mV
3.3 V 3138 mV
5.0 V 4763 mV
1.2 V Rocket IO 1160 mV
1.5 V Rocket IO 1408 mV
1.8 V RLDRAM 1717 mV
I2C Slave Revision 15
For more information about using the CLI, see the Junos OS manuals.
Related
Documentation
MX480 Craft Interface Description on page 14•
• MX480 Routing Engine Description on page 27
Maintaining MX480 DPCs
Purpose The router can have up to six Dense Port Concentrators (DPCs) mounted horizontally in
the DPC card cage at the front of the chassis. For optimum router performance, verify
the condition of the DPCs.
Action On a regular basis:
• Check the LEDs on the craft interface directly above each DPC slot. The green LED
labeled OK lights steadily when a DPC is functioning normally.
• Check the OK/FAIL LED on the DPC. For more information, seeMX Series Interface Module
Reference . If the DPC detects a failure, the DPC sends an alarm message to the Routing
Engine.
• Check the status of installed DPCs by issuing the CLI show chassis fpc command to
check the status of installed DPCs. As shown in the sample output, the value Online
in the column labeled State indicates that the DPC is functioning normally:
user@host> show chassis fpc
Temp CPU Utilization (%) Memory Utilization (%)
Slot State (C) Total Interrupt DRAM (MB) Heap Buffer
0 Online 41 9 0 1024 15 57
Copyright © 2017, Juniper Networks, Inc.420
MX480 3D Universal Edge Router Hardware Guide
