lc-3/0/0 up up
lc-3/0/0.32769 up up vpls
pfe-3/0/0 up up
pfe-3/0/0.16383 up up inet
inet6
pfh-3/0/0 up up
pfh-3/0/0.16383 up up inet
coc12-3/0/1 up up
coc12-3/0/2 up up
coc12-3/0/3 up up
...
See Also MX480 Router Hardware and CLI Terminology Mapping on page 12•
MX480 PIC LEDs
Each PIC has LEDs located on the faceplate. For more information about LEDs on the
PIC faceplate, see the “LEDs” section for each PIC in the MX Series Interface Module
Reference.
See Also PICs Supported by MX240, MX480, and MX960 Routers on page 68•
• MX480 PIC Description on page 66
• Replacing an MX480 PIC on page 350
• Maintaining MX480 PICs on page 433
PICs Supported by MX240, MX480, and MX960 Routers
Table 46 on page 68 lists the PICs supported by MX240, MX480, and MX960 routers.
Table 46: PICs Supported by MX240, MX480, and MX960 Routers
First Junos OS ReleaseTypePortsPIC Model NumberPIC Name
Channelized IQ PICs
9.524PB-4CHOC12-STM4-IQE-SFPChannelized OC12/STM4 Enhanced
IQ (IQE) PIC with SFP
9.521PB-1CHOC48-STM16-IQEChannelized OC48/STM16 Enhanced
IQ (IQE) PIC with SFP
SONET/SDH PICs
9.524PB-4OC3-1OC12-SON2-SFPSONET/SDH OC3/STM1 (Multi-Rate)
PIC with SFP
9.524PB-4OC3-4OC12-SON-SFPSONET/SDH OC12/STM4
(Multi-Rate) PIC with SFP
10.4R234PC-4OC48-STM16-IQE-SFPSONET/SDH OC48/STM16 Enhanced
IQ (IQE) PIC with SFP
