Table 46: PICs Supported by MX240, MX480, and MX960 Routers (continued)
First Junos OS ReleaseTypePortsPIC Model NumberPIC Name
9.521PB-1OC48-SON-B-SFPSONET/SDH OC48/STM16
(Multi-Rate) PIC with SFP
9.434PC-4OC48-SON-SFPSONET/SDH OC48/STM16 PIC with
SFP
9.431PC-1OC192-SON-VSRSONET/SDH OC192c/STM64 PIC
9.431PC-1OC192-SON-XFPSONET/SDH OC192c/STM64 PIC with
XFP
See Also MX Series FPC and PIC Overview•
• FPCs Supported by MX240, MX480, and MX960 Routers on page 65
• High Availability Features
Interface Modules—MPCs and MICs
•
MIC/MPC Compatibility on page 69
•
MX480 Modular Interface Card (MIC) Description on page 76
•
MX480 MIC Port and Interface Numbering on page 77
•
MX480 Modular Interface Card (MIC) LEDs on page 80
•
MICs Supported by MX Series Routers on page 80
•
MX480 Modular Port Concentrator (MPC) Description on page 87
•
MX480 Modular Port Concentrator (MPC) LEDs on page 90
•
MPCs Supported by MX Series Routers on page 90
•
MX480 Application Services Modular Line Card Description on page 93
•
MX480 Application Services Modular Storage Card Description on page 96
•
MX480 Application Services Modular Processing Card Description on page 97
•
MX480 AS MSC LEDs on page 97
•
MX480 AS MXC LEDs on page 98
MIC/MPC Compatibility
The following tables provide a compatibility matrix for the MICs currently supported by
MPC1, MPC2, MPC3, MPC6, MPC8, and MPC9 on MX240, MX480, MX960, MX2008,
MX2010, MX2020, and MX10003 routers. Each table lists the first Junos OS release in
which the MPC supports the MIC. For example, Junos OS Release 10.2 is the first release
in which the MX-MPC1-3D supports the Gigabit Ethernet MIC with SFP. An en dash
indicates that the MIC is not supported.
