RJ-45 Connector Pinouts for MX Series Routing Engine AUX and CONSOLE Ports
The ports on the Routing Engine labeled AUX and CONSOLE are asynchronous serial
interfaces that accept an RJ-45 connector. The ports connect the Routing Engine to an
auxiliary or console management device. Table 75 on page 138 describes the RJ-45
connector pinout.
Table 75: RJ-45 Connector Pinout for the AUX and CONSOLE Ports
DescriptionSignalPin
Request to SendRTS1
Data Terminal ReadyDTR2
Transmit DataTXD3
Signal GroundGround4
Signal GroundGround5
Receive DataRXD6
Data Set ReadyDSR/DCD7
Clear to SendCTS8
Related
Documentation
• MX480 Routing Engine Description on page 27
• RJ-45 Connector Pinouts for an MX Series Routing Engine ETHERNET Port on page 137
