Two LEDs, located on the craft interface above the FPC, that display the status of the
FPC and are labeled OK and FAIL
•
FPC online/offline button, located on the craft interface above the FPC
See Also MX480 Flexible PIC Concentrator (FPC) LEDs on page 65•
• Maintaining MX480 FPCs on page 425
• MX480 FPC Terminology
• Troubleshooting the MX480 FPCs on page 444
• Replacing an MX480 FPC on page 332
MX480 Flexible PIC Concentrator (FPC) LEDs
Two LEDs, located on the craft interface above the FPC, that display the status of the
FPC and are labeled OK and FAIL. For more information about the FPC LEDs located on
the craft interface, see “FPC LEDs on the MX480 Craft Interface” on page 17.
See Also MX480 Flexible PIC Concentrator (FPC) Description on page 63•
• Maintaining MX480 FPCs on page 425
• MX480 FPC Terminology
• Troubleshooting the MX480 FPCs on page 444
• Replacing an MX480 FPC on page 332
FPCs Supported by MX240, MX480, and MX960 Routers
An FPC occupies two slots when installed in an MX240, MX480, or MX960 router. The
maximum number of supported FPCs varies per router:
•
MX960 router—6 FPCs
•
MX480 router—3 FPCs
•
MX240 router—1 FPC
Table 45 on page 65 lists FPCs supported by MX Series routers.
Table 45: FPCs Supported by MX Series Routers
First Junos OS
Release
Maximum
Throughput per FPC
(Full-duplex)
Maximum
Number of PICs
SupportedFPC Model NumberFPC NameFPC Type
9.420 Gbps2MX-FPC3FPC33
9.510 Gbps2MX-FPC2FPC22
65Copyright © 2017, Juniper Networks, Inc.
Chapter 6: Line Card Components and Descriptions
