MX480 Router Physical Specifications
Table 68 on page 119 summarizes the physical specifications for the router chassis.
Table 68: Physical Specifications
HeightDepthWidthWeightDescription
14.0 in. (35.6 cm)24.5 in. (62.2 cm)
(from front to chassis
rear)
Total depth (including
cable management
brackets) 27.75 in.
(70.5 cm)
17.45 in. (44.3 cm)Chassis with
midplane, fan tray, air
filter, and cable
management
brackets: 65.5 lb
(29.7 kg)
Maximum
configuration:
221.03 lb (100.26 kg)
Chassis dimensions
1.25 in (3.2 cm)7.75 in (19.7 cm)11 in (27.9 cm)2.4 lb (1.1 kg)Routing Engine (RE-S-1800)
1.19 in (3.02 cm)7.47 in (18.97 cm)10.7 in (27.18 cm)2.69 lb (1.18 kg)Routing Engine (RE-S-X6-64G)
1.25 in (3.2 cm)22 in (55.9 cm)17 in (43.2 cm)9.6 lb (4.4 kg) (with
Routing Engine
installed)
SCB
