CHAPTER 11
Cable and Pinout Specifications
•
RJ-45 Connector Pinouts for an MX Series Routing Engine ETHERNET Port on page 137
•
RJ-45 Connector Pinouts for MX Series Routing Engine AUX and CONSOLE
Ports on page 138
RJ-45 Connector Pinouts for an MX Series Routing Engine ETHERNET Port
The port on the Routing Engine labeled ETHERNET is an autosensing 10/100-Mbps
Ethernet RJ-45 receptacle that accepts an Ethernet cable for connecting the Routing
Engine toa managementLAN (orother devicethat supports out-of-band management).
Table 74 on page 137 describes the RJ-45 connector pinout.
Table 74: RJ-45 Connector Pinout for the Routing Engine ETHERNET Port
SignalPin
TX+1
TX–2
RX+3
Termination network4
Termination network5
RX–6
Termination network7
Termination network8
Related
Documentation
MX480 Routing Engine Description on page 27•
• RJ-45 Connector Pinouts for MX Series Routing Engine AUX and CONSOLE Ports on
page 138
137Copyright © 2017, Juniper Networks, Inc.
