Table 101: Field-Replaceable Units
Hot-Pluggable FRUsHot-Removable and Hot-Insertable FRUs
•
Master Switch Control Board (SCB) (if
nonstop active routing is not configured)
•
Master Routing Engine (if nonstop active
routing is not configured)
•
Switch Control Board (SCB) (nonredundant)
•
Routing Engine (nonredundant)
•
Solid-statedrives (SSDs) of RoutingEngines
•
Air filter
•
Craft interface
•
Backup Switch Control Board (SCB) (if
redundant)
•
Master Switch Control Board (SCB) (if
nonstop active routing is configured)
•
Backup Routing Engine (if redundant)
•
Master Routing Engine (if nonstop active
routing is configured)
•
Dense Port Concentrators (DPCs)
•
Flexible PIC Concentrators (FPCs)
•
Modular Port Concentrators (MPCs)
•
Modular Interface Cards (MICs)
•
PICs
•
AC and DC power supplies (if redundant)
•
Fan tray
Related
Documentation
MX480 Component Redundancy on page 11•
• Tools and Parts Required to Replace MX480 Hardware Components on page 248
Tools and Parts Required to Replace MX480 Hardware Components
To replace hardware components, you need the tools and parts listed in
Table 102 on page 248.
Table 102: Tools and Parts Required
ComponentsTool or Part
•
Alarm relay terminal block2.5-mm flat-blade (–) screwdriver
•
DC power supply
•
Cables and connectors
7/16-in. (11 mm) nut driver or socket
wrench
•
DPC
•
FPC
•
PIC
•
MPC
•
MIC
•
Power supply
•
Routing Engine
•
SCB
Blank panels (if component is not
reinstalled)
