Juniper MX480 - RE-S-1800 Routing Engine Boot Sequence; RE-S-1800 Routing Engine Leds; Table 14: Routing Engine Leds

•
RESET button—Reboots the Routing Engine when pressed.
•
ONLINE/OFFLINE button—Takes the Routing Engine online or offline when pressed.
•
Extractor clips—Used for inserting and extracting the Routing Engine.
•
Captive screws—Secure the Routing Engine in place.
NOTE: For specific information about Routing Engine components (for
example, the amount of DRAM), issue the show chassis routing-engine
command.
RE-S-1800 Routing Engine Boot Sequence
The router is shipped with Junos OS preinstalled on the Routing Engine. There are three
copies of software:
•
One copy on the CompactFlash card in the Routing Engine.
•
One copy on the hard disk in the Routing Engine.
•
One copy on a USB flash drive that can be inserted into the slot on the Routing Engine
faceplate.
The Routing Engine boots from the storage media in this order: the USB device (if present),
then the CompactFlash card, then the Solid State Disk (SSD), then the LAN. Normally,
the router boots from the copy of the software on the CompactFlash card.
Related
Documentation
• RJ-45 Connector Pinouts for MX Series Routing Engine AUX and CONSOLE Ports
• RJ-45 Connector Pinouts for an MX Series Routing Engine ETHERNET Port
• Replacing an MX960 Routing Engine
• Supported Routing Engines by Router on page 40
RE-S-1800 Routing Engine LEDs
Each Routing Engine has four LEDs that indicate its status. The LEDs, labeled MASTER,
STORAGE, ONLINE, and OK/FAIL, are located directly on the faceplate of the Routing
Engine. Table 14 on page 31 describes the functions of the Routing Engine LEDs.
Table 14: Routing Engine LEDs
DescriptionStateColorLabel
Routing Engine is the Master.On steadilyBlueMASTER
Indicates activity on the SSD or Compact Flash.BlinkingGreenSTORAGE
