Table 68: Physical Specifications (continued)
HeightDepthWidthWeightDescription
1.25 in (3.2 cm)22 in (55.9 cm)17 in (43.2 cm)9.6 lb (4.4 kg) (with
Routing Engine
installed)
SCBE
1.25 in (3.2 cm)22 in (55.9 cm)17 in (43.2 cm)9.6 lb (4.4 kg) (with
Routing Engine
installed)
SCBE2
1.25 in (3.2 cm)22 in (55.9 cm)17 in (43.2 cm)Maximum up to 14.5
lb (6.6 kg)
Blank panel in DPC
slot: 9 lb
DPC
2.5 in (6.4 cm)22 in (55.9 cm)17 in (43.2 cm)FPC2: 13 lb (5.9 kg)
FPC3: 14 lb (6.5 kg)
FPC
4.125 in (10.5 cm)11.125 in (19.7 cm)7.75 in (28.3 cm)2 lb (0.9 kg)PIC
1.25 in (3.2 cm)22 in (55.9 cm)17 in (43.2 cm)18.35 lb (8.3 kg)MPC (fixed configuration)
1.25 in (3.2 cm)22 in (55.9 cm)17 in (43.2 cm)14 lb (6.4 kg)MPC (without MICs)
1.25 in (3.2 cm)6.8 in (17.3 cm)6.25 in (15.9 cm)Maximum up to 1.2 lb
(0.54 kg)
MIC
6.25 in (15.9 cm)8.5 in (21.6 cm)21.25 in (54 cm)1.1 lb (0.5 kg)Craft interface
1.5 in (3.8 cm)22 in (55.9 cm)17 in (43.2 cm)6.8 lb (3.08 kg)Fan tray
10.1 in (25.6 cm)22.23 in (56.5 cm)0.31 in (0.8 cm)1.0 lb (0.5 kg)Air filter
9.9 in (25.0 cm)4.5 in (11.4 cm)0.25 in (0.6 cm)0.3 lb (0.14 kg)Cable management brackets
1.75 in (4.4 cm)4 in (10.2 cm)14.5 in (36.8 cm)3.8 lb (1.7 kg)DC power supply
1.75 in (4.4 cm)4 in (10.2 cm)14.5 in (36.8 cm)6.2 lb (2.81 kg)High-capacity DC power supply
1.75 in (4.4 cm)4 in (10.2 cm)14.5 in (36.8 cm)5.0 lb (2.3 kg)AC power supply
1.75 in (4.4 cm)4 in (10.2 cm)14.5 in (36.8 cm)6.6 lb (2.99 kg)High-capacity AC power supply
Related
Documentation
MX480 Chassis Lifting Guidelines on page 488•
• MX480 Router Description on page 3
• MX480 Chassis Description on page 9
