Diagnostic Information 2-27
4023-001
281 Paper Jam
Open Cover M
Paper is jammed in the
transport of the finisher.
• Open finisher cover M
to access jam area.
Check horizontal transport
sensors and actuators for
PC1, PC2. Replace the
finisher main board if
necessary. Replace the
printer main engine board
PWB-A if necessary.
Go to:
•
“Paper Feed In Hori-
zontal Transport Ser-
vice Check” on
page 2-48
.
•
“Paper Feed Finisher
Service Check” on
page 2-50
.
281 Paper Jam
Open Doors I,J
Paper is jammed in the
transport of the mailbox.
• Separate the mailbox
from the printer.
• Open doors I and J to
access jam area.
Go to
“Paper Feed
Mailbox Service Check”
on page 2-48
.
282 Paper Jam
Open Cover N
Paper is jammed in the
finishing bin.
• Open the finishing bin
cover N to access jam
area.
• Clear all paper from
the finishing bin.
Check horizontal transport
sensors and actuators for
PC1, PC2. If necessary,
replace main board PWB-A
located in failing option.
Replace the printer main
engine board PWB-A if
necessary.
Go to:
•
“Paper Feed In Hori-
zontal Transport Ser-
vice Check” on
page 2-48
.
• “Paper Feed Finisher
Service Check” on
page 2-50
.
Message Description Action
