Lexmark Optra W810 - Page 136

2-28 Service Manual
4023-001
283 Paper Jam
Cover N
A stapler jam has
occurred and is
displayed as a paper
jam.
• Open the finishing bin
cover N to access jam
area.
Check horizontal transport
sensors and actuators for
PC1, PC2. If necessary,
replace main board PWB-A
located in failing option.
Replace the printer main
engine board PWB-A if
necessary.
Go to:
•
“Paper Feed In Hori-
zontal Transport Ser-
vice Check” on
page 2-48
.
•
“Paper Feed Finisher
Service Check” on
page 2-50
.
284 Paper Jam
Open Cover M
Paper is jammed in the
eject option area.
• Open cover M to
access jam area or,
• Separate the finisher
from the printer.
Check horizontal transport
sensor and actuator for
PC1, PC2. If necessary,
replace main board PWB-A
located in failing option.
Replace the printer main
engine board PWB-A if
necessary.
Go to:
•
“Paper Feed In Hori-
zontal Transport Ser-
vice Check” on
page 2-48
.
• “Paper Feed Finisher
Service Check” on
page 2-50.
Message Description Action
