MacDon D1 Series - Page 6

Section
Summary of Change
Internal Use
Only
• To avoid bodily injury or death from unexpected start-up or
fall of raised machine, always stop engine, remove key, and
engage safety props before going under machine for any
reason.
3.4 Attaching Reel Height Sensor,
page 133
• Figure 3.285, page 134
• ECN 58283: Added AGCO IDEAL
™
to picture legend.
• Added arrows to the picture.
ECN 58283
Tech Pubs
3.4 Attaching Reel Height Sensor,
page 133
• See NOTE below Figure
3.285, page 134
Added the following to the NOTE:
• For configuration (A), pointer (D) points to the FRONT of the
header.
• For configuration (B), pointer (D) points to the REAR of the
header.
Product Support
5.5 Unloading with a Combine,
page 162
• Step 10, page 162
Added reference to combine manual.
Tech Pubs
6.1 Installing Filler Cap, page 175
• Step 2, page 175
• Step 3, page 176
• Step 4, page 176
Updated picture to show change to hydraulic tank filler neck.
ECN 57856
6.1 Installing Filler Cap, page 175 Removed step:
•“Apply hydraulic pipe controlled strength pipe thread sealant
(Loctite
®
565 or equivalent) to screws.”
ECN 59259
6.1 Installing Filler Cap, page 175
• Step 6, page 176
• Step 9, page 177
Updated picture to show change to hydraulic tank filler neck.
ECN 57856
6.2 FM100 Feed Auger
Configurations, page 178
Narrow configuration as the standard configuration: Added
AGCO IDEAL
™
Series
ECN 59301
6.2 FM100 Feed Auger
Configurations, page 178
Narrow configuration: Added information about the quantity of
flightings and fingers.
Tech Pubs
6.2 FM100 Feed Auger
Configurations, page 178
Medium configuration as the standard configuration: Added the
following combines:
• Case IH 2300/2500 Series
• Case IH 5/6/7150, 7/8/9250
• CLAAS 7000/8000
• John Deere S76/77/78/790
• New Holland CR 10.80/10.90
• Rostselmash Torum 760/780
Engineering
Tech Pubs
6.2 FM100 Feed Auger
Configurations, page 178
Medium configuration as the standard configuration:
Tech Pubs
215184 iv Revision A
