Section
Summary of Change
Internal Use
Only
inadequate equipment may result in vehicle tipping, machine
damage, or chain breakage.
Lifting Two Headers, page 15 Changed the following IMPORTANT to a WARNING for
consistency:
• Equipment used for loading and unloading must meet or
exceed the minimum specified requirements. Using
inadequate equipment may result in vehicle tipping, machine
damage, or chain breakage.
Tech Pubs
2.4 Lowering Header, page 16
• Step 6, page 19
Added pictures to identify the center-link anchor on single and
double-reel headers.
Product Support
3.1.4 Attaching Center Support –
Double Reel, page 35
• Step 1, page 35
Added the following to the step:
• Retain for reinstallation.
Tech Pubs
3.1.6 Attaching Cam Arms, page
37
• Step 5, page 38
Changed the picture to make the step generic to five, six, and
nine-bat reels.
Tech Pubs
3.1.6 Attaching Cam Arms, page
37
• Step 6, page 38
Added the IMPORTANT to emphasize the correct installation of
the shim.
Product Support
3.1.6 Attaching Cam Arms, page
37
• Figure 3.47, page 39
Added picture of nine-bat reel for additional reference.
Tech Pubs
3.1.6 Attaching Cam Arms, page
37
• Step
Added step. Tech Pubs
3.2.6 Assembling Draper, page
54
Removed the following WARNING ONLY because the header is
considered to be inoperative and not fully assembled at this point
in the manual:
• To avoid bodily injury or death from unexpected start-up or
fall of raised machine, always stop engine, remove key, and
engage safety props before going under machine for any
reason.
Tech Pubs
Installing Right Reel, page 82
• Step 18, page 85
Corrected reference to next step in manual.
Tech Pubs
3.3.5 Installing Deck, page 97
• Step 14, page 100
Reworded step as follows to be consistent with 12, page 53.
• Adjust deck height to obtain clearance (A) of 7–11 mm
(1/8–7/16 in.) between top of deck and inside cutterbar
(i.e., the thickness of the draper plus 3 mm).
Tech Pubs
3.2.6 Assembling Draper, page
54
Removed the following WARNING ONLY because the header is
considered to be inoperative and not fully assembled at this point
in the manual:
Tech Pubs
215184 iii Revision A
