Omron Q2V Series User Manual

5.2 European Standards
152 SIEPCYEUOQ2V01A Q2V Technical Manual
Model Terminal
Recommended Gauge
mm
2
Applicable Gauge
mm
2
Wire Stripping
Length
*1
mm
Terminal Screw
Tightening Torque
N∙m (in∙lb)
2082
R/L1, S/L2, T/L3 35 10 - 50 20
M6
5 - 5.5
(45 - 49)
U/T1, V/T2, W/T3 25 10 - 35 20
M6
5 - 5.5
(45 - 49)
-, +1, +2 50 16 - 70 20
M6
5 - 5.5
(45 - 49)
B1, B2 16 4 - 16 10
M4
1.5 - 1.7
(13.5 - 15)
16 10 - 25 -
M6
5.4 - 6.0
(47.8 - 53.1)
*1 Remove insulation from the ends of wires to expose the length of wire shown.
*2 If you turn on the internal EMC filter, the leakage current of the drive will be more than 3.5 mA. Use these closed-loop crimp
terminals or equivalent to connect a protective ground wire that has a minimum cross-sectional area of 10 mm
2
(copper wire).
• 8-4NS from JST Mfg. Co., Ltd.
• R8-4S from NICHIFU Co.,Ltd.
Single-Phase 200 V Class (CE-compliance)
Model Terminal
Recommended Gauge
mm
2
Applicable Gauge
mm
2
Wire Stripping
Length
*1
mm
Terminal Screw
Tightening Torque
N∙m (in∙lb)
B001
L/L1, N/L2 2.5 2.5 6.5
M3
0.5 - 0.6
(4.4 - 5.3)
U/T1, V/T2, W/T3 2.5 2.5 6.5
M3
0.5 - 0.6
(4.4 - 5.3)
-, +1 2.5 2.5 6.5
M3
0.5 - 0.6
(4.4 - 5.3)
B1, B2 2.5 2.5 6.5
M3
0.5 - 0.6
(4.4 - 5.3)
2.5
*2
2.5
*2
-
M3.5
0.8 - 1.0
(7.1 - 8.9)
B002
L/L1, N/L2 2.5 2.5 6.5
M3
0.5 - 0.6
(4.4 - 5.3)
U/T1, V/T2, W/T3 2.5 2.5 6.5
M3
0.5 - 0.6
(4.4 - 5.3)
-, +1 2.5 2.5 6.5
M3
0.5 - 0.6
(4.4 - 5.3)
B1, B2 2.5 2.5 6.5
M3
0.5 - 0.6
(4.4 - 5.3)
2.5
*2
2.5
*2
-
M3.5
0.8 - 1.0
(7.1 - 8.9)
B004
L/L1, N/L2 2.5 2.5 6.5
M3
0.5 - 0.6
(4.4 - 5.3)
U/T1, V/T2, W/T3 2.5 2.5 6.5
M3
0.5 - 0.6
(4.4 - 5.3)
-, +1 2.5 2.5 6.5
M3
0.5 - 0.6
(4.4 - 5.3)
B1, B2 2.5 2.5 6.5
M3
0.5 - 0.6
(4.4 - 5.3)
2.5
*2
2.5
*2
-
M3.5
0.8 - 1.0
(7.1 - 8.9)
