Omron Q2V Series User Manual

Standards Compliance
5
5.2 European Standards
SIEPCYEUOQ2V01A Q2V Technical Manual 153
Model Terminal
Recommended Gauge
mm
2
Applicable Gauge
mm
2
Wire Stripping
Length
*1
mm
Terminal Screw
Tightening Torque
N∙m (in∙lb)
B006
L/L1, N/L2 2.5 2.5 - 4 8
M3
0.5 - 0.6
(4.4 - 5.3)
U/T1, V/T2, W/T3 2.5 2.5 - 4 8
M3
0.5 - 0.6
(4.4 - 5.3)
-, +1 2.5 2.5 - 4 8
M3
0.5 - 0.6
(4.4 - 5.3)
B1, B2 2.5 2.5 - 4 8
M3
0.5 - 0.6
(4.4 - 5.3)
2.5
*2
2.5 - 6
*2
-
M4
1.2 - 1.5
(10.6 - 13.3)
B010
L/L1, N/L2 2.5 2.5 - 4 8
M3
0.5 - 0.6
(4.4 - 5.3)
U/T1, V/T2, W/T3 2.5 2.5 - 4 8
M3
0.5 - 0.6
(4.4 - 5.3)
-, +1 2.5 2.5 - 4 8
M3
0.5 - 0.6
(4.4 - 5.3)
B1, B2 2.5 2.5 - 4 8
M3
0.5 - 0.6
(4.4 - 5.3)
2.5
*2
2.5 - 6
*2
-
M4
1.2 - 1.5
(10.6 - 13.3)
B012
L/L1, N/L2 4 2.5 - 6 10
M4
1.5 - 1.7
(13.5 - 15)
U/T1, V/T2, W/T3 2.5 2.5 - 4 10
M4
1.5 - 1.7
(13.5 - 15)
-, +1 4 2.5 - 6 10
M4
1.5 - 1.7
(13.5 - 15)
B1, B2 2.5 2.5 - 4 10
M4
1.5 - 1.7
(13.5 - 15)
4
*2
2.5 - 6
*2
-
M4
1.2 - 1.5
(10.6 - 13.3)
B018
L/L1, N/L2 6 2.5 - 10 10
M4
1.5 - 1.7
(13.5 - 15)
U/T1, V/T2, W/T3 2.5 2.5 - 4 10
M4
1.5 - 1.7
(13.5 - 15)
-, +1 6 2.5 - 10 10
M4
1.5 - 1.7
(13.5 - 15)
B1, B2 2.5 2.5 - 4 10
M4
1.5 - 1.7
(13.5 - 15)
6
*2
4 - 10
*2
-
M5
2.0 - 2.5
(17.7 - 22.1)
*1 Remove insulation from the ends of wires to expose the length of wire shown.
*2 If you turn on the internal EMC filter, the leakage current of the drive will be more than 3.5 mA. Use these closed-loop crimp
terminals or equivalent to connect a protective ground wire that has a minimum cross-sectional area of 10 mm
2
(copper wire).
• 8-4NS from JST Mfg. Co., Ltd.
• R8-4S from NICHIFU Co.,Ltd.
