11.20 Defaults by Drive Model and Duty Rating ND/HD
410 SIEPCYEUOQ2V01A Q2V Technical Manual
No.
*1
Name Unit Default
- Drive Model - 2001 2002 2004 2006
C6-01
ND/HD Duty
Selection
-
HD ND HD ND HD ND HD ND
0 1 0 1 0 1 0 1
o2-04
Drive KVA
Selection
Hex. 60 61 62 63
E2-11
(E4-11, E5-
02)
Motor Rated
Power (kW)
kW 0.1 0.2 0.2 0.4 0.4 0.75 0.75 1.1
L8-09
Ground Fault
Selection
- 0 0 0 0 0 0 0 0
n1-03
HuntPrev
Time Constant
ms 10 10 10 10 10 10 10 10
n3-02
HSB CurrLim
Level
1 150 120 150 120 150 120 150 120
n5-02
Mot Inertia
Acceleration
Time
s 0.178 0.178 0.178 0.142 0.178 0.142 0.142 0.142
*1 Parameters within parentheses are for motor 2.
No.
*1
Name Unit Default
- Drive Model - 2008 2010 2012 2018
C6-01
ND/HD Duty
Selection
-
HD ND HD ND HD ND HD ND
0 1 0 1 0 1 0 1
o2-04
Drive KVA
Selection
Hex. 64 65 66 67
E2-11
(E4-11, E5-
02)
Motor Rated
Power (kW)
kW 1.1 1.5 1.5 2.2 2.2 3.0 3.0 3.7
b3-04
SpSrch V/F
Gain
% 100 100 100 100 100 100 100 100
b3-06
Speed Curr
Lev1 for
Estimation
- 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5
b3-08
Speed ACR
PGain for
Estimation
- 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5
b3-26
Dir. Determ.
Level
- 1000 1000 1000 1000 1000 1000 1000 1000
b8-03
eSave Filter
Time
s 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5
b8-04
eSave Coef.
Value
- 196.6 169.4 169.4 156.8 156.8 136.4 136.4 122.9
C6-02
Carrier
Frequency
Selection
- 3 7 3 7 3 7 3 7
E2-01
(E4-01)
Mot Rated
Current (FLA)
A 4.9 6.2 6.2 8.5 8.5 11.4 11.4 14
E2-02
(E4-02)
Mot Rated
Slip
Hz 2.6 2.6 2.6 2.9 2.9 2.7 2.7 2.73
E2-03
(E4-03)
Mot No-Load
Current
A 2.3 2.8 2.8 3 3 3.7 3.7 4.5
E2-05
(E4-05)
Motor L-L
Resistance
Ω 3.577 1.997 1.997 1.601 1.601 1.034 1.034 0.771
E2-06
(E4-06)
Motor Leak
Inductance
% 18.5 18.5 18.5 18.4 18.4 19 19 19.6
E2-10
(E4-10)
Motor Iron
Loss
W 38 53 53 77 77 91 91 112
E5-01
PM Mot Code
Selection
- FFFF FFFF FFFF FFFF FFFF FFFF FFFF FFFF
L2-02
RideThrough
Time@Power
Loss
s 0.3 0.3 0.3 0.3 0.5 0.5 1 1
L2-03
Min Baseblck
Time
s 0.4 0.4 0.4 0.5 0.5 0.5 0.5 0.6
To Next Page
