Omron Q2V Series User Manual

11.21 Parameters Changed by PM Motor Code Selection
428 SIEPCYEUOQ2V01A Q2V Technical Manual
No. Name Unit Motor Code (setting value of E5-01)
n5-02
Mot Inertia Acceleration
Time
s 0.062 0.044 0.080 0.090 0.067 0.072
n8-49 Heavy Load Id Current % -8.8 -9.9 -9.3 -10.0 -17.7 -12.3
*1 The default setting changes when the setting for o2-04 [Drive KVA Selection] changes.
Table 11.18 SSR1 Series Motor Code Setting for Specification of 200 V at 1150 min
-1
(r/min)
No. Name Unit Motor Code (setting value of E5-01)
E5-01
PM Mot Code Selection - 140B 140D 140E 140F 1410
Voltage Class V 200 200 200 200 200
Capacity kW 7.5 11 15 18.5 22
Motor Rotation Speed min
-1
1150 1150 1150 1150 1150
E5-02 PM Mot Rated Power (kW) kW 7.5 11.0 15 18.50 22.00
E5-03 PM Mot Rated Current (FLA) A 26.67 39.9 55.6 63.5 74.4
E5-04 PM Mot Pole Count - 6 6 6 6 6
E5-05
PM Mot Resistance (Ohms/
Phase)
Ω 0.165 0.113 0.084 0.066 0.048
E5-06
PM d-Axis Inductance (mH/
Phase)
mH 6.59 4.96 3.83 3.33 2.38
E5-07
PM q-Axis Inductance (mH/
Phase)
mH 8.55 6.12 4.65 4.50 3.15
E5-09
PM BackEMF Vpeak (mV/(rad/
s))
mVs/rad 391.5 384.4 372.1 421.3 410.9
E5-24
PM BackEMF L-L Vrms (mV/
rpm)
mV/min
-1
0.0 0.0 0.0 0.0 0.0
E1-04 Max Output Frequency Hz 57.5 57.5 57.5 57.5 57.5
E1-05 Max Output Voltage V 190.0 190.0 190.0 190.0 190.0
E1-06 Base Frequency Hz 57.5 57.5 57.5 57.5 57.5
E1-09 Min Output Frequency Hz 2.9 2.9 2.9 2.9 2.9
L3-24
*1
Acc@Rated Torque s 0.088 0.073 0.062 0.091 0.092
n5-02 Mot Inertia Acceleration Time s 0.088 0.073 0.062 0.091 0.092
n8-49 Heavy Load Id Current % -15.3 -13.9 -14.4 -17.9 -15.9
*1 The default setting changes when the setting for o2-04 [Drive KVA Selection] changes.
Table 11.19 SSR1 Series Motor Code Setting for Specification of 400 V at 1150 min
-1
(r/min)
No. Name Unit Motor Code (setting value of E5-01)
E5-01
PM Mot Code Selection - 1432 1433 1435 1436 1438 143A
Voltage Class V 400 400 400 400 400 400
Capacity kW 0.4 0.75 1.5 2.2 3.7 5.5
Motor Rotation Speed min
-1
1150 1150 1150 1150 1150 1150
E5-02 PM Mot Rated Power (kW) kW 0.4 0.75 1.5 2.2 3.7 5.5
E5-03 PM Mot Rated Current (FLA) A 0.94 1.51 3.00 4.43 7.08 10.10
E5-04 PM Mot Pole Count - 6 6 6 6 6 6
E5-05
PM Mot Resistance (Ohms/
Phase)
Ω 19.320 10.800 4.456 2.044 1.483 1.215
E5-06
PM d-Axis Inductance (mH/
Phase)
mH 194.70 129.20 76.88 48.60 37.58 44.54
E5-07
PM q-Axis Inductance (mH/
Phase)
mH 252.84 160.90 97.52 61.40 47.65 56.26
E5-09
PM BackEMF Vpeak (mV/
(rad/ s))
mVs/rad 640.9 654.1 728.8 688.9 702.0 861.5
E5-24
PM BackEMF L-L Vrms
(mV/rpm)
mV/min
-1
0.0 0.0 0.0 0.0 0.0 0.0
E1-04 Max Output Frequency Hz 57.5 57.5 57.5 57.5 57.5 57.5
E1-05 Max Output Voltage V 380.0 380.0 380.0 380.0 380.0 380.0
