Parameter List
11
11.21 Parameters Changed by PM Motor Code Selection
SIEPCYEUOQ2V01A Q2V Technical Manual 427
Table 11.16 SSR1 Series Motor Code Setting for Specification of 400 V at 1450 min
-1
(r/min)
No. Name Unit Motor Code (setting value of E5-01)
E5-01
PM Mot Code Selection - 133B 133D 133E 133F 1340 1342
Voltage Class V 400 400 400 400 400 400
Capacity kW 7.5 11 15 18.5 22 30
Motor Rotation Speed min
-1
1450 1450 1450 1450 1450 1450
E5-02 PM Mot Rated Power (kW) kW 7.5 11.0 15 18.50 22.00 30.00
E5-03 PM Mot Rated Current (FLA) A 13.85 19.5 27.4 32.9 37.6 52.5
E5-04 PM Mot Pole Count - 6 6 6 6 6 6
E5-05
PM Mot Resistance (Ohms/
Phase)
Ω 0.713 0.393 0.295 0.223 0.164 0.137
E5-06
PM d-Axis Inductance (mH/
Phase)
mH 27.06 15.51 12.65 9.87 7.90 7.01
E5-07
PM q-Axis Inductance (mH/
Phase)
mH 33.45 19.63 15.87 12.40 10.38 8.68
E5-09
PM BackEMF Vpeak (mV/
(rad/ s))
mVs/rad 670.1 612.7 624.6 610.4 655.4 708.4
E5-24
PM BackEMF L-L Vrms
(mV/rpm)
mV/min
-1
0.0 0.0 0.0 0.0 0.0 0.0
E1-04 Max Output Frequency Hz 72.5 72.5 72.5 72.5 72.5 72.5
E1-05 Max Output Voltage V 380.0 380.0 380.0 380.0 380.0 380.0
E1-06 Base Frequency Hz 72.5 72.5 72.5 72.5 72.5 72.5
E1-09 Min Output Frequency Hz 3.6 3.6 3.6 3.6 3.6 3.6
L3-24
*1
Acc@Rated Torque s 0.084 0.096 0.085 0.080 0.122 0.108
n5-02
Mot Inertia Acceleration
Time
s 0.084 0.096 0.085 0.080 0.122 0.108
n8-49 Heavy Load Id Current % -12.2 -15.5 -15.1 -16.0 -15.7 -11.5
*1 The default setting changes when the setting for o2-04 [Drive KVA Selection] changes.
Table 11.17 SSR1 Series Motor Code Setting for Specification of 200 V at 1150 min
-1
(r/min)
No. Name Unit Motor Code (setting value of E5-01)
E5-01
PM Mot Code Selection - 1402 1403 1405 1406 1408 140A
Voltage Class V 200 200 200 200 200 200
Capacity kW 0.4 0.75 1.5 2.2 3.7 5.5
Motor Rotation Speed min
-1
1150 1150 1150 1150 1150 1150
E5-02 PM Mot Rated Power (kW) kW 0.4 0.75 1.5 2.2 3.7 5.5
E5-03 PM Mot Rated Current (FLA) A 1.88 3.02 6.00 8.85 14.27 20.21
E5-04 PM Mot Pole Count - 6 6 6 6 6 6
E5-05
PM Mot Resistance (Ohms/
Phase)
Ω 4.832 2.704 1.114 0.511 0.412 0.303
E5-06
PM d-Axis Inductance (mH/
Phase)
mH 48.68 32.31 19.22 12.15 7.94 11.13
E5-07
PM q-Axis Inductance (mH/
Phase)
mH 63.21 40.24 24.38 15.35 11.86 14.06
E5-09
PM BackEMF Vpeak (mV/
(rad/ s))
mVs/rad 320.4 327.1 364.4 344.4 357.5 430.8
E5-24
PM BackEMF L-L Vrms
(mV/rpm)
mV/min
-1
0.0 0.0 0.0 0.0 0.0 0.0
E1-04 Max Output Frequency Hz 57.5 57.5 57.5 57.5 57.5 57.5
E1-05 Max Output Voltage V 190.0 190.0 190.0 190.0 190.0 190.0
E1-06 Base Frequency Hz 57.5 57.5 57.5 57.5 57.5 57.5
E1-09 Min Output Frequency Hz 2.9 2.9 2.9 2.9 2.9 2.9
L3-24
*1
Acc@Rated Torque s 0.062 0.044 0.080 0.090 0.067 0.072
