Parameter Details
12
12.7 H: TERMINALS
SIEPCYEUOQ2V01A Q2V Technical Manual 603
■ 1D: RunCmdSource
Setting Value Function Description
1D RunCmdSource
Shows the selected Run command source.
ON : The keypad is the Run command source.
OFF : Parameter b1-02 or b1-16 [Run Comm. Sel 1 or Run Comm. Sel 2] is the Run command
source.
■ 1E: Motor2 Select
Setting Value Function Description
1E Motor2 Select
The terminal activates when motor 2 is selected.
ON : Motor 2 Selection
OFF : Motor 1 Selection
■ 1F: Restart Enable
Setting Value Function Description
1F Restart Enable
The terminal activates when the Auto Restart function is trying to restart after a fault.
The terminal deactivates when the Auto Restart function automatically resets a fault. The terminal turns off when
the Auto Restart function detects the fault again since Auto Restart function cannot function any longer due to
number of attempts set with L5-01 [Auto-Reset Attempts] being reached.
Note:
Refer to "L5: FAULT RESTART on page 658" for more information.
■ 20: FltReset Active
Setting Value Function Description
20 FltReset Active
The terminal turns on when the drive receives the Reset command from the control circuit terminal, serial communications, or
the communication option.
■ 21: PolePos Detection
Setting Value Function Description
21 PolePos Detection
The terminal activates when drive receives a Run command and the drive detects the motor magnetic pole position of the PM
motor.
■ 22: Ext 24V Supply
Setting Value Function Description
22 Ext 24V Supply
The terminal activates when there is an external 24V power supply between terminals E24V-A0V.
ON : An external 24V power supply supplies power.
OFF : An external 24V power supply does not supply power.
■ 2F: @SpeedSearch
Setting Value Function Description
2F @SpeedSearch
The terminal activates when the drive is doing speed search.
Note:
Refer to “b3: SPEED SEARCH on page 456” for more information.
