Omron Q2V Series - Page 63

Electrical Installation
3
3.3 Main Circuit Wiring
SIEPCYEUOQ2V01A Q2V Technical Manual 63
Single-Phase 200 V Class (UL-compliance)
Model Terminal
Recommended
Gauge
mm
2
Applicable Gauge
mm
2
Wire
Stripping
Length
*1
mm
Terminal Screw
Tightening Torque
N∙m (in∙lb)
Size Shape
B001
L/L1, N/L2 2 2 6.5 M3
0.5 - 0.6
(4.4 - 5.3)
U/T1, V/T2, W/T3 2 2 6.5 M3
0.5 - 0.6
(4.4 - 5.3)
-, +1 2 2 6.5 M3
0.5 - 0.6
(4.4 - 5.3)
B1, B2 2 2 6.5 M3
0.5 - 0.6
(4.4 - 5.3)
2
*2
2
*2
- M3.5
0.8 - 1.0
(7.1 - 8.9)
B002
L/L1, N/L2 2 2 6.5 M3
0.5 - 0.6
(4.4 - 5.3)
U/T1, V/T2, W/T3 2 2 6.5 M3
0.5 - 0.6
(4.4 - 5.3)
-, +1 2 2 6.5 M3
0.5 - 0.6
(4.4 - 5.3)
B1, B2 2 2 6.5 M3
0.5 - 0.6
(4.4 - 5.3)
2
*2
2
*2
- M3.5
0.8 - 1.0
(7.1 - 8.9)
B004
L/L1, N/L2 2 2 6.5 M3
0.5 - 0.6
(4.4 - 5.3)
U/T1, V/T2, W/T3 2 2 6.5 M3
0.5 - 0.6
(4.4 - 5.3)
-, +1 2 2 6.5 M3
0.5 - 0.6
(4.4 - 5.3)
B1, B2 2 2 6.5 M3
0.5 - 0.6
(4.4 - 5.3)
2
*2
2
*2
- M3.5
0.8 - 1.0
(7.1 - 8.9)
B006
L/L1, N/L2 2 2 - 3.5 8 M3
0.5 - 0.6
(4.4 - 5.3)
U/T1, V/T2, W/T3 2 2 - 3.5 8 M3
0.5 - 0.6
(4.4 - 5.3)
-, +1 2 2 - 3.5 8 M3
0.5 - 0.6
(4.4 - 5.3)
B1, B2 2 2 - 3.5 8 M3
0.5 - 0.6
(4.4 - 5.3)
3.5
*2
2 - 5.5
*2
- M4
1.2 - 1.5
(10.6 - 13.3)
B010
L/L1, N/L2 3.5 2 - 5.5 8 M3
0.5 - 0.6
(4.4 - 5.3)
U/T1, V/T2, W/T3 2 2 - 3.5 8 M3
0.5 - 0.6
(4.4 - 5.3)
-, +1 3.5 2 - 5.5 8 M3
0.5 - 0.6
(4.4 - 5.3)
B1, B2 2 2 - 3.5 8 M3
0.5 - 0.6
(4.4 - 5.3)
3.5
*2
2 - 5.5
*2
- M4
1.2 - 1.5
(10.6 - 13.3)
