Parameter Details
12
12.8 L: PROTECTION
SIEPCYEUOQ2V01A Q2V Technical Manual 653
L3-26: DC Bus Capacitors Extension
No.
(Hex.)
Name Description
Default
(Range)
L3-26
(0455)
Expert
DC Bus Capacitors
Extension
Sets the capacity for external main circuit capacitors. Usually it is not necessary to change this
setting. Sets this parameter when you use the KEB Ride-Thru function.
0 μF
(0 to 65000 μF)
L3-27: StallP Detect Time
No.
(Hex.)
Name Description
Default
(Range)
L3-27
(0456)
StallP Detect Time
Sets a delay time between reaching the Stall Prevention level and starting the Stall Prevention
function.
60 ms
(0 - 5000 ms)
L3-34: Torque Lim.Delay Time
No.
(Hex.)
Name Description
Default
(Range)
L3-34
(016F)
Expert
Torque Lim.Delay Time
Sets the filter time constant that returns the torque limit to its initial value when KEB operation
operates in Single Drive KEB Ride-Thru mode.
Determined by A1-02
(0.000 - 1.000 s)
When vibration occurs during operation of Single Drive KEB Ride-Thru 2, increase this parameter in 0.010-unit
increments.
Note:
The Single Drive KEB Ride-Thru 2 mode operates when L2-29 = 2 [KEB Method = Single KEB2 Ride-Thru] and H1-xx = 42 or 43
[Terminal DIx Function Select = KEB Thru2 NC or KEB Thru2 NO].
L3-35: SpAgree Width@StallP
No.
(Hex.)
Name Description
Default
(Range)
L3-35
(0747)
Expert
SpAgree Width@StallP
Sets the width for speed agreement when L3-04 = 1 [StallP@Decel Enable = Enabled] and L3-50
= 1 [StallP@Decel Mode = Automatic Decel Reduction]. Usually it is not necessary to change
this setting.
0.00 Hz
(0.00 - 1.00 Hz)
Set this parameter when hunting occurs while you use a frequency reference through an analog input.
L3-36: VibSup Gain@Accel
No.
(Hex.)
Name Description
Default
(Range)
L3-36
(11D0)
VibSup Gain@Accel
Sets the gain to suppress current and motor speed hunting during operation when L3-01 = 4
[StallP Mode@Accel = ILim Mode]. Usually it is not necessary to change this setting.
Determined by A1-02
(0.0 - 100.0)
If there is vibration in the output current during acceleration, increase the setting value.
Note:
Set L3-01 = 4 [StallP Mode@Accel = ILim Mode] to enable this function.
L3-37: CurLim ITime@Accel
No.
(Hex.)
Name Description
Default
(Range)
L3-37
(11D1)
Expert
CurLim ITime@Accel
Suppresses current hunting during acceleration. Usually it is not necessary to change this setting.
5 ms
(0 - 100 ms)
Note:
Set L3-01 = 4 [StallP Mode@Accel = ILim Mode] to enable this function.
