Omron RX2 Series User Manual

8 Applied Settings
8 - 14
High-function General-purpose Inverter RX2 Series User’s Manual
 PID1 Target Value Selection
Item Parameter Data Description
Default
data
Input source selection
of Set-point for PID1
[AH-07] 00 to 13
00: Invalid, 01: Ai1-L input, 02: Ai2-L input,
03: Ai3-L input, 04: (Reserved),
05: (Reserved), 06: (Reserved),
07: Parameter setting [AH-10],
08: RS 485 communication, 09: Option 1,
10: Option 2, 11: Option 3,
12: Pulse train input (main unit),
13: Pulse train input (option)
07
Set-point-1 setting for
PID1
[AH-10]
0.00 to
100.00[%]
*1
Is a parameter set value. 0.00
PID1 Multi stage
set-point 1 setting
[AH-12]
PID1 Multi stage
set-point 2 setting
[AH-14]
PID1 Multi stage
set-point 3 setting
[AH-16]
PID1 Multi stage
set-point 4 setting
[AH-18]
PID1 Multi stage
set-point 5 setting
[AH-20]
PID1 Multi stage
set-point 6 setting
[AH-22]
PID1 Multi stage
set-point 7 setting
[AH-24]
PID1 Multi stage
set-point 8 setting
[AH-26]
PID1 Multi stage
set-point 9 setting
[AH-28]
PID1 Multi stage
set-point 10 setting
[AH-30]
PID1 Multi stage
set-point 11 setting
[AH-32]
PID1 Multi stage
set-point 12 setting
[AH-34]
PID1 Multi stage
set-point 13 setting
[AH-36]
PID1 Multi stage
set-point 14 setting
[AH-38]
PID1 Multi stage
set-point 15 setting
[AH-40]
Input source selection
of Set-point 2 for PID1
[AH-42] 00 to 13
00: Invalid, 01: Ai1-L input, 02: Ai2-L input,
03: Ai3-L input, 04: (Reserved),
05: (Reserved), 06: (Reserved),
07: Parameter setting [AH-44],
08: RS 485 communication, 09: Option 1,
10: Option 2, 11: Option 3,
12: Pulse train input (main unit),
13: Pulse train input (option)
00
Set-point 2 setting for
PID1
[AH-44]
0.00 to
100.00[%]
*1
Is a parameter set value. 0.00
