High-function General-purpose Inverter RX2 Series User’s Manual
PID2 derivative gain [AJ-15]
0.00 to
100.00(s)
Differential gain 0.00
PID3 enable [AJ-21]
00 Disable
00
01
Enable (if command becomes negative, it
does not output in a reverse direction)
02
Enable (if command becomes negative, it
outputs in a reverse direction)
PID3 deviation inverse [AJ-22]
00 Disable
00
01 Enabled (polarity inversion of deviation)
Input source selection
of Set-point for PID3
[AJ-27] 00 to 13
00: Disable, 01: Ai1-L input, 02: Ai2-L input,
03: Ai3-L input, 04: (Reserved),
05: (Reserved), 06: (Reserved),
07: Parameter setting [AH-44],
08: RS 485 communication, 09: Option 1,
10: Option 2, 11: Option 3,
12: Pulse train input (main unit),
13: Pulse train input (option)
07
Set-point setting for
PID3
[AJ-30]
0.00 to
100.00(%)
*2
Is a parameter set value. 0.00
Input source selection
of Process data for
PID3
[AJ-32] 00 to 13
00: Disable, 01: Ai1-L input, 02: Ai2-L input,
03: Ai3-L input, 04: (Reserved),
05: (Reserved), 06: (Reserved),
07: Parameter setting [AH-44],
08: RS 485 communication, 09: Option 1,
10: Option 2, 11: Option 3,
12: Pulse train input (main unit),
13: Pulse train input (option)
02
PID3 proportional gain [AJ-33] 0.0 to 100.0 Proportional gain 1.0
PID3 integral time con-
stant
[AJ-34] 0.0 to 3600.0(s) Integral gain 1.0
PID3 derivative gain [AJ-35]
0.00 to
100.00(s)
Differential gain 0.00
*1. Data range varies depending on the data from [AJ-04] to [AJ-06].
*2. Data range varies depending on the data from [AJ-24] to [AJ-26].
