9 Communications Functions
9 - 66
High-function General-purpose Inverter RX2 Series User’s Manual
32Ech 32EBh
Decel-stop at power failure
freq. width at deceleration
start
bA-36 R/W 0 to 1000 0.01(Hz)
32Edh 32ECh
Decel-stop at power failure
DC-bus voltage constant con-
trol P-gain
bA-37 R/W 0 to 500 0.01
32Eeh 32EDh
Decel-stop at power failure
DC-bus voltage constant con-
trol I-gain
bA-38 R/W 0 to 15000 0.01(s)
32F0h 32EFh
Over-voltage suppression
enable, 1st-motor
bA140 R/W
00: Disabled
01: DC voltage constant deceler-
ation
02: Acceleration only at decelera-
tion
03: Acceleration at constant
speed/deceleration
-
32F1h 32F0h
Over-voltage suppression
active level, 1st-motor
bA141 R/W
(200Vclass) 3300 to 4000
(400Vclass) 6600 to 8000
0.1(Vdc)
32F2h 32F1h
Over-voltage suppression
action time, 1st-motor
bA142
(HIGH)
R/W
0 to 360000 0.01(s)
32F3h 32F2h
bA143
(LOW)
R/W
32F4h 32F3h
DC bus constant control pro-
portional gain, 1st-motor
bA144 R/W 0 to 500 0.01
32F5h 32F4h
DC bus constant control inte-
gral gain, 1st-motor
bA145 R/W 0 to 15000 0.01(s)
32F6h 32F5h
Over magnetization decelera-
tion function selection,
1st_motor
bA146 R/W
00: Disabled
01: Regular operation
02: Operation only at decelera-
tion
03: Level mode
04: Level mode only at decelera-
tion
-
32F7h 32F6h
Over magnetization output fil-
ter time constant, 1st_motor
bA147 R/W 0 to 100 0.01(s)
32F8h 32F7h
Over magnetization voltage
gain, 1st_motor
bA148 R/W 50 to 400 1(%)
32F9h 32F8h
Over magnetization level set-
ting, 1st_motor
bA149 R/W
(200V class) 3300 - 4000
(400V class) 6600 - 8000
0.1(Vdc)
3304h 3303h Dynamic brake usage rate bA-60 R/W
0.0 - 10.0×([bA-63]/minimum
resistance)
2*2
0.1(%)
3305h 3304h Dynamic brake selection bA-61 R/W
00: Disabled
01: Enabled: disabled at stop
02: Enabled: enabled at stop
-
3306h 3305h Dynamic brake active level bA-62 R/W
(200V class) 3300 - 4000
(400V class) 6600 - 8000
0.1(Vdc)
3307h 3306h Dynamic brake resister value bA-63 R/W
Minimum resistance - 600
*2
0.1(Ω)
330Eh 330Dh
Cooling FAN control method
selection
bA-70 R/W
00: Always ON
01: ON during operation
02: Temperature dependent
-
330Fh 330Eh
Cooling FAN accumulation
running time clear selection
bA-71 R/W
00: Disabled
01: Clear
-
Register
No.
Modbus
register
spec. No.
Function name
Parame-
ter No.
R/W Monitor or setting data Resolution
