9 Communications Functions
9 - 68
High-function General-purpose Inverter RX2 Series User’s Manual
334Ah 3349h
Selection of restart mode
@over-voltage
bb-30 R/W
00: 0Hz
01: Frequency matching
02: Frequency entrainment
03: Detection speed
04: Trip after frequency matching
deceleration stop
-
334Bh 334Ah
Wait time of restart
@over-voltage
bb-31 R/W 0.3 to 100.0 (s) 0.1(s)
3354h 3353h
Restart mode after FRS
release
bb-40 R/W
00: 0Hz
01: Frequency matching
02: Frequency entrainment
03: Detection speed
*4
-
3355h 3354h
Restart mode after RS
release
bb-41 R/W
00: 0Hz
01: Frequency matching
02: Frequency entrainment
03: Detection speed
*4
3356h 3355h Restart frequency threshold bb-42 R/W 0 to 59000 0.01(Hz)
3357h 3356h
Restart level of Active fre-
quency matching
bb-43 R/W
(0.0 to 2.0)
× Inverter rated current
*1
0.1(A)
3358h 3357h
Restart constant(speed) of
Active frequency matching
bb-44 R/W 10 to 3000 0.01(s)
3359h 3358h
Restart constant(Voltage) of
Active frequency matching
bb-45 R/W 10 to 3000 0.01(s)
335Ah 3359h
OC-supress level of Active
frequency matching
bb-46 R/W
(0.0 to 2.0)
× Inverter rated current
*1
0.1(A)
335Bh 335Ah
Restart speed selection of
Active frequency matching
bb-47 R/W
00: Cutoff frequency
01: Maximum frequency
02: Setting frequency
-
3368h 3367h
Over current detection level,
1st-motor
bb160 R/W
(0.2 to 2.2)
x Inverter ND rated current
*1
0.1(A)
3369h 3368h
Power supply over voltage
selection
bb-61 R/W
00: Warning
01: Error
-
336Ah 3369h
Power supply over voltage
level setting
bb-62 R/W
(200V class) 3000 - 4100
(400V class) 6000 - 8200
0.1(Vdc)
336Ch 336Bh Ground fault selection bb-64 R/W
00: Disabled
01: Enabled
-
336Dh 336Ch Input phase loss enable bb-65 R/W
00: Disabled
01: Enabled
-
336Eh 336Dh Output phase loss enable bb-66 R/W
00: Disabled
01: Enabled
-
336Fh 336Eh
Output phase loss detection
sensitivity
bb-67 R/W 1 to 100 1(%)
3372h 3371h Thermistor error level bb-70 R/W 0 to 10000 1(Ω)
337Ch 377Bh Over speed detection level bb-80 R/W 0 to 1500 0.1(%)
337Dh 337Ch Over speed detection time bb-81 R/W 0 to 50 0.1(s)
337Eh 337Dh
Speed deviation error mode
selection
bb-82 R/W
00: Warning
01: Error
-
337Fh 337Eh
Speed deviation error detec-
tion level
bb-83 R/W 0 to 1000 0.1(%)
3380h 337Fh
Speed deviation error detec-
tion time
bb-84 R/W 0 to 50 0.1(s)
3381h 3380h
Position deviation error mode
selection
bb-85 R/W
00: Warning
01: Error
-
Register
No.
Modbus
register
spec. No.
Function name
Parame-
ter No.
R/W Monitor or setting data Resolution
