9 Communications Functions
9 - 78
High-function General-purpose Inverter RX2 Series User’s Manual
3841h 3840h
Low current signal output
mode selection, 1st motor
CE101 R/W
00: During acceleration/decelera-
tion, at constant speed
01: Only at constant speed
-
3842h 3841h
Low current detection level 1,
1st motor
CE102 R/W
(0.0 to 2.0)
× Inverter rated current
*2
0.1(A)
3843h 3842h
Low current detection level 2,
1st motor
CE103 R/W
(0.0 to 2.0)
× Inverter rated current
*2
0.1(A)
3845h 3844h
Over current signal output
mode selection, 1st motor
CE105 R/W
00: During acceleration/decelera-
tion, at constant speed
01: Only at constant speed
-
3846h 3845h
Over current detection level 1,
1st motor
CE106 R/W
(0.0 to 2.0)
× Inverter rated current
*2
0.1(A)
3847h 3846h
Over current detection level 2,
1st motor
CE107 R/W
(0.0 to 2.0)
× Inverter rated current
*2
0.1(A)
384Ah 3849h
Arrival frequency setting
during acceleration 1
CE-10 R/W 0 to 59000 0.01(Hz)
384Bh 384Ah
Arrival frequency setting
during deceleration 1
CE-11 R/W 0 to 59000 0.01(Hz)
384Ch 384Bh
Arrival frequency setting
during acceleration 2
CE-12 R/W 0 to 59000 0.01(Hz)
384Dh 384Ch
Arrival frequency setting
during deceleration 2
CE-13 R/W 0 to 59000 0.01(Hz)
3854h 3853h
Over torque level (Forward
driving), 1st motor
CE120 R/W 0 to 5000 0.1(%)
3855h 3854h
Over torque level (Reverse
regenerative), 1st motor
CE121 R/W 0 to 5000 0.1(%)
3856h 3855h
Over torque level (Reverse
driving), 1st motor
CE122 R/W 0 to 5000 0.1(%)
3857h 3856h
Over torque level (Forward
regenerative), 1st motor
CE123 R/W 0 to 5000 0.1(%)
385Eh 385Dh
Electronic thermal warning
level (MTR)
CE-30 R/W 0 to 10000 0.01(%)
385Fh 385Eh
Electronic thermal warning
level (CTL)
CE-31 R/W 0 to 10000 0.01(%)
3861h 3860h Zero speed detection level CE-33 R/W 0 to 10000 0.01(Hz)
3862h 3861h
Cooling FAN over-heat warn-
ing level
CE-34 R/W 0 to 200 1(°C)
3864h 3863h
Accum.RUN
(RNT)/Accum.Power-on
(ONT) time setting
CE-36
(HIGH)
R/W
0 to 100000 1(hr)
3865h 3864h
CE-37
(LOW)
R/W
3868h 3867h
Window comparator for [Ai1]
higher level
CE-40 R/W 0 to 100 1(%)
3869h 3868h
Window comparator for [Ai1]
lower level
CE-41 R/W 0 to 100 1(%)
386Ah 3869h
Window comparator for [Ai1]
hysteresis width
CE-42 R/W 0 to 10 1(%)
386Bh 386Ah
Window comparator for [Ai2]
higher level
CE-43 R/W 0 to 100 1(%)
386Ch 386Bh
Window comparator for [Ai2]
lower level
CE-44 R/W 0 to 100 1(%)
386Dh 386Ch
Window comparator for [Ai2]
hysteresis width
CE-45 R/W 0 to 10 1(%)
Register
No.
Modbus
register
spec. No.
Function name
Parameter
No.
R/W Monitor or setting data
Resolution
