Omron RX2 Series User Manual

Appendices C Table of Parameters
C - 36
High-function General-purpose Inverter RX2 Series User’s Manual
bA201 -
Frequency limit selection, 2nd
motor
00 (Disabling)/01 (Ai1 terminal input)/
02 (Ai2 terminal input)/03 (Ai3 terminal input)/
04 (Reserved)/05 (Reserved)/06 (Reserved)/
07 (Parameter setting)/08 (RS485)/09 (Option 1)/
10 (Option 2)/11 (Option 3)/
12 (Pulse string input (main body))/
13 (Pulse string input Option)
00
bA202 ○
Upper frequency limit, 2nd
motor
0.00 to 590.00 (Hz) 0.00
bA203 ○
Lower frequency limit, 2nd
motor
0.00 to 590.00 (Hz) 0.00
bA210 -
Torque limit selection,
2nd-motor
00 (Disable)/01 (Ai1 terminal input)/
02 (Ai2 terminal input)/03 (Ai3 terminal input)/
04 (Reserved)/05 (Reserved)/06 (Reserved)/
07 (Parameter setting)/08 (RS 485)/
09 (Option 1)/10 (Option 2)/11 (Option 3)
07
bA211 -
Torque limit parameter mode
selection, 2nd-motor
00 (Four quadrant specific)/
01 ([TRQ] terminal switch)
00
bA212 ○
Torque limit 1 (Forward driving),
2nd-motor
0.0 to 500.0 (%)
(Limited at at torque equivalent to 200% of
inverter ND rating)
150.0 (%)
bA213 ○
Torque limit 2 (Reverse regener-
ative), 2nd-motor
0.0 to 500.0 (%)
(Limited at at torque equivalent to 200% of
inverter ND rating)
150.0 (%)
bA214 ○
Torque limit 3 (Reverse driv-
ing), 2nd-motor
0.0 to 500.0 (%)
(Limited at at torque equivalent to 200% of
inverter ND rating)
150.0 (%)
bA215 ○
Torque limit 4 (Forward regener-
ative), 2nd motor
0.0 to 500.0 (%)
(Limited at at torque equivalent to 200% of
inverter ND rating)
150.0 (%)
bA216 -
Torque limit LADSTOP selec-
tion, 2nd-motor
00 (Disabled)/01 (Enabled) 00
bA220 -
Over current suppress enable,
2nd-motor
00 (Disabled)/01 (Enabled) 01
bA221 -
Over current suppress Level,
2nd-motor
(0.0 to 2.0)
× Inverter rated current (A)
*1
*2
bA222 -
Overload restriction 1 mode
selection, 2nd-motor
00 (Disabled)/
01 (Accelerate at constant speed)/
02 (Only constant speed)/
03 (Accelerate at constant speed/Increase speed
at regeneration)
01
bA223 ○
Overload restriction 1 active
level, 2nd-motor
(0.2 to 2.0)
× Inverter rated current (A)
*1
*3
bA224 ○
Overload restriction 1 action
time, 2nd-motor
0.10 to 3600.00 (s) 1.00
bA226 -
Overload restriction 2 mode
selection, 2nd-motor
00 (Disabled)/
01 (Accelerate at constant speed)/
02 (Only constant speed)/
03 (Accelerate at constant speed/Increase speed
at regeneration)
01
bA227 ○
Overload restriction 2 active
level, 2nd-motor
(0.2 to 2.0)
× Inverter rated current (A)
*1
*3
bA228 ○
Second overload limit 2 opera-
tion time
0.10 to 3600.00 (s) 1.00
bA240 ○
Over-voltage suppression
enable, 2nd-motor
00 (Disabled)/
01 (DC voltage constant deceleration)/
02 (Acceleration only at deceleration)/
03 (Acceleration at constant speed/deceleration)
00
bA241 ○
Over-voltage suppression active
level, 2nd-motor
(200 V class) 330.0 to 400.0 (V)
(400 V class) 660.0 to 800.0 (V)
(200 V class) 380.0
(400 V class) 760.0
Code
Codes that
can be
changed
during
operation
Name Data range Initial value Note
