PREVOST X3-45 COMMUTER User Manual

SECTION 18: BODY
DOB 1300-1556 | X3-45 Commuter PA-1648 Maintenance Manual First release Oct 2020
41
FIGURE 62: FLATNESS CHECK
19. Check proper power window sliding inside
window frame.
20. If applicable, remove excess of adhesive all
around door frame using Sika 208.
21. From the inside of the door, apply some
sealant Sika 221 between door skin panel
and frame and on welding spots as per
Figure 63.
FIGURE 63: SEALANT APPLICATION
22. Apply some #680066 glue inside fiber glass
groove and fix power window wiper.
NOTE
Anti-friction side must be on glass side.
FIGURE 64: ANTI-FRICTION SIDE
23. From inside the door, apply some Sika 252
at the corners of window wiper.

PREVOST X3-45 COMMUTER Specifications

General

Engine	Volvo D13
Transmission	Allison B500
Fuel Type	Diesel
Length	45 ft (13.7 m)
Width	102 in (2.6 m)
Horsepower	500 hp
GVWR	54, 000 lbs
Height	141 in
