PREVOST X3-45 COMMUTER User Manual

SECTION 18: BODY
42
DOB 1300-1556 | X3-45 Commuter PA-1648 Maintenance Manual First release Oct 2020
FIGURE 65: WINDOW WIPER CORNER
24. Apply some #680066 glue inside finishing
panel groove and fix power window wiper.
NOTE
Anti-friction side must be on glass side.
FIGURE 66: ANTI-FRICTION SIDE
25. Install rub rail with fixing bolts.
26. Install windshield washer reservoir, new
reflector amber #930212, door lock, handle
and power window connector.
FIGURE 67: COMPONENTS REINSTALLATION
27. Reinstall the door on the vehicles with the
mounting bolts (4).
FIGURE 68: DOOR MOUNTING BOLTS
28. Tighten bolts to a torque value of 50 lbs-pi.
29. Make sure to keep a minimum of 4 mm and
not very much between the door skin and
the side panel.

PREVOST X3-45 COMMUTER Specifications

General

Engine	Volvo D13
Transmission	Allison B500
Fuel Type	Diesel
Length	45 ft (13.7 m)
Width	102 in (2.6 m)
Horsepower	500 hp
GVWR	54, 000 lbs
Height	141 in
