SECTION 18: BODY
DOB 1300-1556 | X3-45 Commuter PA-1648 Maintenance Manual First release Oct 2020
59
FIGURE 112: DOOR DISMOUNTING
4. Preferably install the door onto a work
surface where it can be solidly fixed.
5. Refer to SAV10054-67.
Baggage Compartment Door Adjustment
6. Adjust door panel top to get a 6mm gap with
the vehicle side panel bottom.
7. All adjustments are to be made with door
closed and with the mounting screws shown
in Figure 113.
FIGURE 113: DOOR MOUNTING SCREWS
8. Center door in the opening using the
retaining rings. Adjust the lateral position by
adding or removing retaining rings in the
location shown in Figure 114.
FIGURE 114: LATERAL ADJUSTMENT
9. Adjust door position and evenness with
reference to adjacent panels and doors.
10. Adjust the door position by moving IN or
OUT the locking plate. Adjust one corner at
a time.
FIGURE 115: EVENNESS ADJUSTMENT
11. Check handle adjustment. Handle must
remain tight against its plastic housing.
