5-22 BRAKES
BRAKES PIPES AND HOSES
SUBSTITUTION
1) Place vehicle in an appropriate working ground.
2) Clean dirt and accumulated impurities at the end of the pipes,
brake hoses and surrounding.
3) Dismantle pipes or hoses plugging the holes to pour out the
minimum possible amount of fluid.
CAUTION:
Brake fluid is extremely damaging paint. If fluid
should accidentally touch painted surface,
immediately wipe fluid from paint and clean painted
surface.
4) Install new pipes or hose, noting the following points:
• Place correctly clips or braces.
• Be sure that the hose is nor twisted neither trapped.
• Be sure that the hose is no contact other parts which could
lead to damaging rubbings.
• Check hose and pipes under steering maximum rotation
condition, right and left. If there are any contacts, remove
and correct it.
• Supply and keep adequate level of brake fluid in the tank.
5) Proceed to purge the braking system (see 5-17).
Brake pipes
Fuel pipes
