6A-90 ENGINE REP
AIR
Rear part
9
)
Block again the flywheel rotation using tool (B) ref. 790976
and remove plate support of ball bearings (63).
63
B
64
65
B
66
1
0
)
Remove screws (65) fixing flywheel (64), take away blocking
tool (B), remove flywheel and dust preventing plate .
1
1
)
Remove assembly cover and rear oil-seal (66).
300
302
