Santana PS-10 User Manual

ENGINE REPAIR 6A-91
Crankshaft and lower block
12) Remove screws (67) fixing lower block (68) to upper block
(69).
13) Remove lower block (68) with gasket.
14) Remove crankshaft (70) using a lifting device .
15) Straighten the braking sheets that put in place the screws
(71) of oil injectors (73); remove screws and withdraw
injectors.
16) Remove the half ball bearings of block (72) located in the
upper and in the lower block.
NOTE:
If the half ball bearings of block (72) are going to be
used again store them in such a way that the original
mounting positions keep identified.
67
68
69
70
71
72
73
