Santana PS-10 User Manual

7A-22 MANUAL TRANSMISSION
51) Remove 1st and 2nd gear synchro (68) and synchro (69)
696869
52) Remove 2nd gear (70) as well as needle roller bearing (71)
and spacer (72).
70
71
72
Removal primary shaft
53) Remove clip (73).
54) Remove fitting washer (74).
55) Remove bearing (75) using an extractor (C).
74 73
C
75
Counter shaft assembly
56) Remove rear bearing (76) and front bearing (78) assembly.
57) Using an universal extractor (C), remove the inner ring (77)
from both bearings.
C
77
76
78
