TRANSFER BOX 7D-13
8) Remove:
• The bearing (9).
• The worm gear (10).
• Bush (11).
9
10
11
12
13
14
A
9) Dismount the bush oil collector and remove seal (12) from
the exterior part.
10) Take off clip (13) which fixes the bearing support.
Check
1) Service all the components of the speedometer casing and
check for wear and tear and possible deformations.
2) Examine the state of the outlet bearing grooves, worm gear
and speedometer gears.
11) Dismount rear outlet support bearing (14), making use of
soft stick (A).
