Santana PS-10 User Manual

TRANSFER BOX 7D-19
12) Dismount outside ring (20) from the rear bearing using a
copper rod (A).
13) Remove assembly washer (21).
14) Remove drive gear (23) two bearings (22) using a bearing
extractor (B).
15) Unscrew setscrews (24), remove separator (25) from
transfer box and lever box housing.
25
A
20
21
22
B
23
24
16) Put the "high/low" selector in the high position.
17) Loosen screw (26) which fixes the yoke selector and remove
it.
27
26
