7D-26 TRANSFER BOX
10) Install, provisionally, the speedometer casing (37) fixing it
with its screws (36).
NOTE:
This operation is carried out to position the exterior
ring of the rear bearing while the main shaft is being
fitted.
36
37
11) Place, provisionally, main transfer shaft assembly (39) in its
housing in transfer box.
39
7) Brake previously fitted nut (70) locking the nut rib in the
shaft groove.
8) Fit main shaft front bearing, placing it deeply in its housing.
9) Sink exterior ring (38) into the main shaft rear bearing, leaving
it flush with box face.
38
70
