Santana PS-10 User Manual

TRANSFER BOX 7D-31
41) Fit double traction assembly box (29), applying the sealant
recommended to the joint face, and fix with screws (28) to
the specified torque.
Torque for double traction setscrews:
2,2 ÷ 2,8 Kg-m (22 ÷ 28 Nm)
42) Put high/low selector shaft in the high position.
43) Fit selector yoke (27) and fix using locking bolt (26).
28
29
26
27
NOTE:
Make sure that the yokes face one another perfectly.
44) Apply the recommended sealant to separator joint face (25)
and fix with screws to the specified torque.
Torque for separator setscrews:
2,2 ÷ 2,8 Kg-m (22 ÷ 28 Nm)
25
24
